Detailed Product Description
Main specification:
1. Model: UF-20AB ; UF-30AB
2. Maximum input power: UF-20AB: 20KW; UF-30AB:30KW
3. Oscillatging frequency: UF-20AB: 50-250MHZ; UF-30AB:50-200KHZ
4. Input voltage: 380V, three phase, 50HZ or 60HZ
5. Duty cycle: 100%
6. Cooling water desire: 6L/min 0.2Mpa
7. Water temperature protection point: <45oC
8. Auto heating time, retaining time: 0.1-99.9Sec.
9. Weight and size:
|
Model |
N.W/G.W kg |
SIZE LxWxH mm |
Packing size LxWxH mm |
|
UF-20AB controller |
27kg/32kg |
550x260x550mm |
650x360x650mm |
|
UF-20AB transformer |
22kg/27kg |
490x260x370mm |
590x360x470mm |
|
UF-30AB controller |
29kg/34kg |
550x260x550mm |
650x360x650mm |
|
UF-30A transformer |
24kg/29kg |
490x260x370mm |
590x360x470mm |
Features:
1. With high frequency up to 250KHZ, the quenching thickness can be controlled lower than 1~1.5mm.
2. IGBT module and inverting technologies of third generation been used, higher reliability and lower maintenance cost.
3. 100% duty cycle, conetinuous working is allowed at maximum power output.
4. Constant current or constant power status can be selected accordingly to achieve higher heating efficiency.
5. Display of heating power and heating current and oscillating frequency.
6. Simple to install, installation can be done by unprofessional person very easily.
7. Light weight, 50KG only.
8. Advantages of the timer: the power and the operating time of the heating period and the retain period can be preset respectively, to realize a simple heating curve, this model is suggested to use for batch production to improve the repeatability.
9. The separated model are designed to fit the dirty surrounding of some cases.
