sell pvc window machine

Detailed Product Description

This machine is the special equipment for the welding of vingle profiles and rectangle welding in a ringle with advanced technology, stability and compact structure. This machine uses in pneumatic driving and the imported complete line pain gives the machine eary operation and high accuracy. The computer controlling system( programming control) enlarged the reliability and ensures the high efficiently. This machine is suitable for large volume production. The pneumatic driving system uses the imported parts of excellent performance and longevity. The controlling part are imported computer for industry, the driving system uses the imported step-by-step motor and imported timing belt which ensure the orientation accuracy and durability.
Working Air Pressure
0.5-0.8MPa
Air Consumption
200L/min
Power Supply
380V/50Hz
Input Power
11KW
Welding Dimension Range
300*300-1800*3000mm
Welding Profile Height
20-120mm
Welding Profile Width
0-120mm
Outside Dimension
5500*1750*3000mm
Weight
3200Kg
