Four Point Welding Machine CNC

Prev Product

Next Product

Detailed Product Description

Features:

Used for automatically realizing the welding of frame.

Profile clamps with cutters, which adjust welding seam between 0.2mm-2mm, can respectively satisfy the processing demand for colored and common profile

Adopt AC Servo Drive System, high reliability.

Adopt Ball Screw Shaft transmission to realize machine head horizontal moving, also Wire core hold-in belt to realize machine head vertical moving, high precision.

The movement of head upper clamping location and feeding adapt slide guide kinematics pair, capacity credibility.

Parallel Welding Type: Special “Know-how” technique strengthens corner welding.

Change the welding paddle conveniently, high quality products.

Two pieces profiles welding (less than 65mm) at one time is available, high efficiency.

Adapt high quality pneumatic components, high technique in processing and assemble increased processing precision, machine reliability and stability.

To meet customer’s requirement, can add clamping preheating device.

This machine is a high-class four corner welding machine, especially used for making high-class PVC window and door.

Parameter

Input Voltage:   3N～50Hz 380V/220V
Input Power:      9(kw)
Operation Air Pressure:0.5～0.8(MPa)
Air Consumption:  200(L/min)
Welding Height:   25～160 (mm)
Welding Width:    130 (mm)
Welding Range:   400×400～1800×3000 (mm)
Overall Dimension: 5000×2000×2850（mm）
Machine Weight:   3000(kg)

Post Date:	5/8/2009
Expiry Date:	5/3/2010
