IP Speed Dome is the convenient solution for an Internet or private IP camera. With its direct Ethernet connection it can instantly be connected to the network or an in-house intranet and be up in running in just minutes.IP Speed Dome uses H.263 compression standards to compress and encode the video image, then sends out over the network by TCP/IP protocol. It can be operated independently without computer. User on the Ethernet network and user on the INTERNET can access it by standard explorer browser. Users can use it to real-time monitor the object in all directions.
IP Speed Dome has many powerful functions, plug and play. Because of the integrated distribution replacement of the trouble CCTV cabling, the video monitoring system using network camera really amalgamates the digital network and CCTV network into one network.
Features:
1、IP Speed Dome uses H.263 compression standards to compress and encode the video image, then sends out over the network by TCP/IP protocol.
2、Connected directly to Ethernet ( either 10 or 100M), it can carry out long-distance transmission.
3、built in one 10M/100M Ethernet interface(RJ-45), plug and play.
4、With the ability of image division and control of PTZ Speed-Dome.
5、built in WEB Server, enabling users to remotely view and/or manage the camera from a standard Web browser on any computer, anywhere, at any time.
6、several levels of password protection.
7、built in real-time operate system(RTOS),support software download and configuration. It is convenient for net camera updating and management.
Specifications:
| Model |
Outdoor IP Slow Speed Dome |
| PIC |
Ethernet 10/100M |
|
Video parameter |
Compressed format: MPEG-4 |
|
Resolution:D1(720*576),
CIF(352*288), QCIF(176*144) |
|
Protocol |
TCP/IP, PING, HTTP, UDP |
|
Max frames per second |
25 Frame/s（PAL） 30 Frame/s（NTSC） |
|
Compression Rate |
10~200 : 1 |
|
Customer connect |
20 users in Max |
|
Image sensor |
1/4'' sony super HAD CCD 420TV |
|
White balance |
Auto |
|
Min. illumination |
0.7Lux or 0.01Lux |
|
Lens focal length |
F=3.2 ~ 86.4mm, 27íZOOM |
|
Focus & Iris |
AUTO/manual |
|
Preset |
12 |
|
Pan speed |
0 ~ 15/s |
0 ~ 240/s |
|
Tilt speed |
0 ~ 15/s |
0 ~ 120/s |
|
Pan rotation |
360 continuously |
|
Tilt rotation |
90 |
|
Work temperature |
-10℃~55℃ |
|
Relative humidity |
20%~80%RHG |
|
Power source |
AC 24V |
|
Power consumption |
20VA |
|
Weight |
5.2kg |
|
Dimensions |
Seven-inches |
Numerous application possibilities
IP Speed Dome can be used to:
1.Remotely monitor places, people, pets and manufacturing processes.
2.Provide remote product demos, consultations or teaching.
3.Secure the safety of people or property anywhere.
4.Display live images on Web sites for promotion purposes
