diesel generator

Next Product

Detailed Product Description

Generator	model	CED6500S		CED6500S3
	Rated frequency(Hz)	50	60	50	60
	Rated voltage(V)	220, 230, 240, 220/110, 230/115, 240/120		380/220, 400/230, 420/240
	Rated output power(kVA)	4. 2	4. 5	4. 2	4. 5
	Rated rotation speed(rpm)	3000	3600	3000	3600
	DC output	12V7A
	Power factor cos	1		0. 8
	Phase number	Single phase		Three phase
	Excitation mode	self-excitation Brush type		self-excitation constant voltage
	Noise level[dBA/7m] (zero load~full load)	70~74
	Overall dimension [mm] (L×W×H)	970×580×785(38. 19×22. 83×30. 91)
	Dry weight [kg(1bs)]	186(409. 20)
	Structure model	Silent
	Connection mode	Single bearing, rotor drive shaft rigid coupling
Engine	Engine model	CF186FE
	Engine type	Single cylinder, 4-stroke air-cooled, vertical, diesel engine
	Displacement[cm³(cu-in)]	406(24. 78)
	Compression ratio	19: 1
	Rated power [kW(Hp)/rpm]	6. 3(8. 6)/3600
	Starting system	Electric starting
	Ratation direction (from the flywheel)	Clockwise
	Fuel type	0#(summer), -10#(winter)diesel oil
	Lube brand	SAE10W30(above CC grade)
	Low oil pressrue alarm system	With
