Thermoplastic paint kettle

Specially designed for fast, efficient melting thermoplastic paint material at construction spot. Available with single kettle or double kettle, skid or trailer mounted

1. Engine: 18 HP water-cooled or wind-cooled electric startup diesel engine. Max rotating speed: 2200r/min.

2. Agitator: Hydraulically driven, in clockwise and anti-clockwise direction.

3. Hydraulic oil tank: Capacity: 50L. Hydraulic oil: 68#

4. Heating system: LPG heating system. Temperature:0-30 degree C free adjustable. (50kg LPG jar supplied by user).

5. Melting Kettle: Single kettle or double-kettlevertical, with vertical hydraulic agitator.

6. Safety device: With fire extinguisher and automatical protective device for overloading

Model       Capacity (kg)

RFS400    2x200  truck mounted

RFS700     2x350  truck mounted

 RFS1000   2x500  truck mounted

RFD200     200  truck mounted

RFD350      350  truck mounted

RFD450     450  truck mounted

RFL700     2x350 trailer mounted
