3.6mm Board Lens 1.5" Mini Dome Infared Camera with CDS Auto Control

Payment Terms:	L/C

Inquiry Now

motor brush holder made in China

Price:3.00-30.00 USD/Piece

Min. Order:1 Piece
Dust Collector Air Filter Media

Price:1.00 USD/Ton

Min. Order:6 Tons
Decoration bar for Highlander

Price:

Min. Order:
Kia Besta Door Sliding Roller Assy

Price:1.00-4.00 USD/Piece

Min. Order:1000 Pieces
220V 2000W Engine Heater CE & ROHS & EA...

Price:10.00-20.00 USD/Piece

Min. Order:108 Pieces

Place of Origin:	Beijing in China

Specifications

3.6mm Board Lens 1.5" Mini Dome Infared Camera with CDS Auto Control

Features:
1.5" Plastic Mini Dome Camera
3.6mm Standard Lens
Auto White Balance(AWB)

Model	VCDVG9	VCDVG7	VCDVG5	VCDVG4	VCDVG1
Image Sensor	1/3' SONY CCD	1/3' SONY CCD	1/3' SONY CCD	1/3' SONY CCD	1/4' SHARP CCD
Horizontal Resolution	600TV Lines Low Illumination	540TV Lines Low Illumination	480TV Lines	420TV Lines
Pixels	PAL:795 (H)× 596(V) NTSC :811 (H) ×508 (V)	PAL:752(H)×582(V), NTSC:768(H)×494(V)		PAL:500(H)×582(V) NTSC:510(H)×492(V)
TV System	PAL/NTSC
Lens	3.6mm Board lens
Sync System	Internal
IR Status	No
Usable Illumination	0.001Lux/F2.0		0.0005Lux/F2.0		0.01Lux/F2.0
IR Power On	CDS Auto Control
S/N Ratio	≥54dB (AGC OFF)		≥48dB (AGC OFF)
Gamma Correction	0.45
Video Out	Composite Signal (1.0Vp-p, 75Ω)
Scanning System	PAL:625 Lines, 50 Field/Sec;NTSC:525 Lines, 60 Field/Sec
Electronic Shutter Time	Auto:PAL 1/50-1/100, 000Sec;NTSC 1/60-1/100, 000Sec
Operation Temperature	-10℃~ +50℃RH95% Max
Storage Temperature	-20℃~ +60℃RH95% Max
White Balance	Auto
Power Source	DC12V 450mA
Dimension	Size:(H)56 x 67.3(D) mm
Weight	250g
