Specifications
In industrial production, the belt conveyor can be used as a link contributing to the continuous production between production machinery equipments, so as to achieve the continuity and automation during the whole production process, to improve the productivity and reduce the labor strength. It is widely applied in the conveying and production lines in mining, metallurgy, chemical, casting, and building material industries, as well as other production sectors, such as the construction site of a hydropower station and a port to convey bulk materials and end products. According to the process requirements, the conveying work can be done with a single belt conveyor, or with a horizontal or slant conveying system consisting of several belt conveyers, or of the belt conveyor and other conveying equipments to meet different demands of the operation line with different types of work. The belt conveyor can be used in the environment with the temperature ranging from －20℃to +40℃, and the temperature of the material being conveyer is below 50℃. The conveying distance of the belt conveyor manufactured by our company may be determined according to customers' demands.
Technical Data:
| Belt Width(mm) | Belt Length (m) / Power (kW) | Belt Speed (m/s) | Capacity (t/h) | ||
| 500 | ≤12/3 | 12-20/4-5.5 | 20-30/5.5-7.5 | 1.3-1.6 | 45-100 |
| 650 | ≤12/4 | 12-20/5.5 | 20-30/7.5-11 | 1.3-1.6 | 70-120 |
| 800 | ≤10/4 | 10-15/5.5 | 15-30/7.5-15 | 1.3-1.6 | 120-180 |
| 1000 | ≤10/5.5 | 10-20/7.5-11 | 20-40/11-22 | 1.3-2.0 | 160-250 |
| 1200 | ≤10/7.5 | 10-20/11 | 20-40/15-30 | 1.3-2.0 | 200-400 |
Highlights:
The belt moves according to the friction transmission principle, with advantages of large conveying capability, long conveying distance, stable conveying, non-existence of relative movement between the material and the belt, low noise, simple structure, easy to maintain, little energy consumption, part standardization, etc.
Working Principle:
The belt conveyor mainly consists of the rack, conveying belt, belt roller, tension device, transmission device. The machine body is made of the high-quality steel plates connected with each other, forming a rack based on the height difference between the front and back legs. The plane is slant with a certain slant angle. The belt roller, carrier roller, etc are installed on the rack, used to drive and support the conveying belt. The driving mode includes speed-reducing motor driving and electric-roller driving.
Applications:
1. Belt conveyer can be used in processing granite
In the whole granite crushing line, Large-sized granites are transferred to jaw crusher through vibrating feeder from hopper for first crushing, then belt conveyor transferred the crushed granites to impact crusher for secondary crushing. The crushed granites will be transferred to the vibrating screen, and separated to different sizes. After that, belt conveyer will transfer the aggregate with suitable size to the final product pile and aggregate with unsuitable size to the impact crusher for re-crushing. The sizes of final products will be graded and separated according to customers' requirements.
2. Belt conveyer can be used in quarry industry
A quarry is a type of open-pit mine from which rock or minerals are extracted. Quarries are generally used for extracting building materials, such as dimension stone, construction aggregate, riprap, sand, and gravel. In the whole production process, belt conveyer can be used to transfer sandy or lump materials.
3. Belt conveyer can be used in sand making production line
The whole sand-making production line consists of vibrating feeder, jaw crusher, VSI vertical shaft impact crusher (sand-making machine), vibrating screen, sand-washing machine, belt conveyor, electric control system, etc. In sand production line, belt conveyer is used to transfer the crushed materials by jaw crusher to sand making machine for secondary crushing.
