Honto Denki Gear Motor Co., Ltd.
China Manufacturer with main products: Micro Motor, AC Motor, Gear Motor, Induction Motor, Torque Motor, Reversible Motor, Speed Control Motor, Magnetic Brake Motor |
Related products from verified members
-
Price:0.13-0.15 USD/PieceMin. Order:50,000 Pieces -
Price:500.00-5,000.00 USD/PieceMin. Order:1 Piece
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Taiwan |
Specifications
Able to change speed when running. Separate and compose type of controller are available. Multiple function use with separate type. Compose type use independent connection device, simplified wiring.
- Output from 6W to 120W.
- Range of speed adjustment is 50Hz : 90~1400, 60Hz : 90~1600.
- Wiring has separate or composes types to choose.
- Gently start or stop function is attached with separate type.
- Insulation resistance: Use a DC500V high resistance gauge to measure the coil of motor and it's an outer shell when motor running in normal temperature and normal humidity, its value should be above 100MΩ.
- Insulation pressure endurance: Apply 60Hz, 1.5kV at the coil of motor and it's an outer shell for one minute without and extraordinary phenomenon when motor running in normal temperature and normal humidity.
- Temperature arises: Install two reduction gears or radiation plate of the same class at the motor. After rated running, test the coil by resistance method. Its value should be less than 80°C.
- Insulation Class: Class B (130°C).
- Overheat protection: Over heat shut down system.
- Environment temperature: -10°C~+50°C.
- Humid around the environment: Below 85% (No frosting happens).
