Csbattery 12V 200ah/250ah/300ah Storage Lead-Acid AGM Battery for Car/Motorcycle/EPS/Boat/Power-Tool/Pack/Cse
| FOB Price: | 1.00 - 800.00 USD/Piece |
|---|---|
| Payment Terms: | T/T |
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
Related products from verified members
Quick Details
- Nominal Capacity: 300
- Size: See Below Table
- Nominal Voltage: 12V
- Type: AGM+Acid
- Brand Name: Csbattery
Specifications
Model NO.
GB12 General TypeInstallation
FixedRechargeable
ChargeableModel
Max 12V300ah 6V420ahColor
Black / Dark GrayVoltage
12V 6VWarranty
3 YearsExpected Cycle Life
15~20 YearsDelivery
15-20daysMark
Duralbe VRLA BatteryCertificates
CE, IEC, ISOTerminal
M5/M6/M8Casing
ABS or UL94 Fire ResistanceProof
Water Proof, Non SpillableWeight/Size
See below TableTrademark
CSBattery/OEM(free)Transport Package
Carton/PalletSpecification
Deep Cycle DOD50% 800Origin
Guangzhou, GuangdongHS Code
8507200000
GB SERIES SEALED FREE MAINTENANCE VRLA AGM BATTERY
Voltage: 12V
Capacity: 12V15Ah~12V250Ah
Designed floating service life: 8-10 years @ 25 °C/77 °F.
Summary for solar agm battery
CSBattery GB series lead acid batteries are designed to have a large amount of stored current discharged between charging sessions, with very heavy non-porous battery plates to withstand repeated major discharging and charging cycle. the CSBattery VRLA AGM battery uses a different chemistry for the plates active paste material, and a slightly stronger electrolyte than normal battery electrolyte, thus the GB range features 30% higher cyclic life with 10 years of float life when compared to the other standard Duration range.
Features and Advantages for sealed free maintenance lead acid battery
30% more cyclic life through innovation at the PAM additives
Long life expectancy of 10 years in floating condition
Thick flat plate with high Tin low Calcium alloy
Wide operating temperature range from -20 °C to 50°C
3% Low self-discharge rate
Very good deep cycle performance: up to 700 cycles @50% DOD
Excellent deep discharge recovery capability
Construction for VRLA AGM battery
Positive plate - Thick high Sn low Ca grid with special paste
Negative plate - Balanced Pb-Ca grid for improved recombination efficiency
Separator - Advanced AGM separator for high pressure cell design
Electrolyte - Dilute high purity sulfuric acid
Battery container and cover -Fire resistance ABS, water proof
Pillar seal - Two layers epoxy resin seal
Relief valve - Complete with integrated flame arrestor
Applications for VRLA SMF battery
Electric Powered Vehicles, Golf Cars and Buggies, Wheel Chairs, Power Tools, Electric Powered Toys, Control System, Medical Equipments, UPS systems, Inverter systems, Servers, Telecom, Emergency systems, Security systems, and so on.
Charging voltage and settings for Sealed MF VRLA AGM battery
L. Constant voltage charging is recommended
2. Recommended float charge voltage: 2.27V/cell @20~25°C
3. Float voltage temperature compensation: -3mV/°C/cel l
4. Float voltage range: 2.27 to 2.30 V/cell @ 20~25°C
5. Cyclic application charge voltage: 2.40 to 2.47 V/cell @ 20~25°C
6. Max. Charge current allowable: 0.25C
