Tobee 8x6S-HH High Head Slurry Pump Is a World's Standard Heavy Duty Slurry Pumps

Specifications

8x6S-HH High Head Slurry Pump is a world's standard heavy duty slurry pumps and have outstanding performance in high head applications, It is widely used in the mining, coal washing, power plant, metallurgy, petrochemical, building material, dredging, and other industrial departments, etc. The 8x6 high head slurry pumps are suitable for handling high abrasive slurries of various concentrations including hydrocyclone feeding pumps, magnetic separator feeding pumps, underflow slurry pumps (thickener underflow pumps, filter separator underflow pumps), flotation feeding pumps, vibrating sieve feeding pumps, shaking grading pressure pumps, concentrate pump, tailing pumps etc.

Design Features:

√ Ductile iron fully lined casing provides durability, strength and long service life.

√ Multi-stage high pressure operation to 750 psi.

√ Heavy duty construction with through-bolt design provides ease of maintenance and minimal downtime.

√ Large diameter, slow turning, high efficiency impellers designed to achieve maximum wear life and low operating costs.

√ Large, open internal passages designed to maximize wear life and lower operating costs.

√ Thick elastomer and alloy liners provide superior corrosion resistance and maximum wear life.

√ Full flush gland, low flow, and dry running centrifugal seals reduce flush water usage minimizing pump operating costs.

Tobee 8/6 S HH High Head Slurry Pumps Applications:

HH high head slurry pumps widely used for wet crushers, SAG mill discharge, ball mill discharge, rod mill discharge, Ni acid slurry, coarse sand, coarse tailings, phosphate matrix, minerals concentrate, heavy media, dredging, bottom/fly ash, lime grinding, oil sands, mineral sands, fine tailings, phosphoric acid, coal, flotation, sugar beets, process chemical, pulp and paper, FGD, waste water etc.

* Tobee is a registered trademark and does not represent or is not in any way affiliated with Warman of Weir Minerals Group. All names,numbers, symbols and descriptions are used for reference purpose only and do not imply that any pumps or parts listed is the product of Warman Pumps.

* Tobee 8/6S-HH high head slurry pumps and spares are only interchangeable with Warman 8/6S-HH high head slurry pumps and spares.
