Industry Door / Gate Operator Industry Sectional Shaft Motor

Supply Ability:	10,000 Bag(s) per Month
Shipping:	20 days
Payment Terms:	T/T

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Zhejiang in China
Packaging Details:	cartons

Quick Details

Type: Gate Operators
Brand Name: Xianfeng
Type: KG50S Kg120S kg400
Dimensions: 40
Weight: 35
Model Number: KG50S KG120S KG400

Specifications

the DC Series sliding gate operators are used to drive sliding gates for residential and industrial uses. the operators can be fitted with gear wheel or chain wheel according to your needs, and featured with powerful starting strength, capable of overwork at short time. the operator can be powered be storage battery in case of power failure. An emergency release key allows operate gate manually. Nice appearance, relilbal quality and easy installation. Working principle and main structure the device is designed for chain link and includes: a DC motor, worm wheel, worm, tool body, control box, motor base, storage battery and limit switch. the motor rotates the worm and worm wheel, which drive the chain wheel and chain, thus the gate was driven to move.

Single phase

--KG40 Power supply 220V, Max. Output torque 40N.M

--KG50 Power supply 220V, Max. Output torque 30N.M
--KG60 Power supply 220V, Max. Output torque 60N.M

--KG100 Power supply 220V, Max. Output torque 100N.M
--KG400 Power supply 220V, Max. Output torque 200N.M
Three phase
--KG50S Power supply 380V, Max. Output torque 50N.M

--KG70S Power supply 380V, Max. Output torque 70N.M
--KG120S Power supply 380V, Max. Output torque 120N.M

--KG200S Power supply 380V, Max. Output torque 200N.M
--KG400S Power supply 380V, Max. Output torque 400N.M
--KG500S Power supply 380V, Max. Output torque 500N.M
