Underwater Camera (NK-2110CDWH)

In Stock

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Place of Origin:	Guangdong in China
Packaging Details:	Standard package

Specifications

*Underwater Camera Image sensor: 1/3 Super Had B/W CCD Sony

* Effective pixels: NTSC of 512 * 492 V, PAL of 500 * 582 V

* Resolution: 480TV lines

* Synchronizing system: internal

* Scanning system: NTSC 525 Lines PAL 625 Lines 2:1 Interlace

* Video output: 1.0 Vp-p / 75 ohms

* Audio output: auto

* S/N ratio: More than 50 dB (AGC Off)

* Min. Illumination: 0.5Lux w/o LED / 0Lux with LED on

* White balance: auto

* Gain control: auto

* Gamma characteristic: auto r equal to 0.45

* Auto Iris control: video / DC switchable

* Shutter speed: NTSC: 1/60…1/100,000 sec, PAL:1/50…1/100,000 sec

* Led spectrum: 850 nm 45 degree IR LED x 12 EA

* IR view distance: 10 m

* Power source: 12 VDC / 1 Amp

* Operating current: 240 mA w / regulated 12V DC

* Standard lens: 6.0 mm

* Optional lens: 16.0 mm, 12.0 mm, 8.0 mm, 3.6 mm

* Operating Temperature: -10℃ - +50℃

* Humidity: within 90 percent RH

* Output terminal: DIY cable with BNC-Female for Video, DC Jack-Male for Power 30M Cable

* Measurement (mm): 70 (D) * 70 (L)

* Weight(Approx. G):1000 g
