Power LED flat light

FOB Price:	1.00 - 100.00 USD/Shenzhen

In Stock

Inquiry Now

Specifications

Power LED Flat Light is my development department new product , applies to various AC90 ~ 260 V power sources suitable orchestrate. Power LED Flat Lightadopt integrated bar-like high-power LED light merit such as brightness height, irradiating brightness for a short time, homogeneously , rise low , various colour of temperature being all in readiness for the illuminant, has volume. And can need the Power LED Flat Light designing , producing various specification , power , colour , use according to the customer. Power LED Flat Light applies to lamp such as various vehicle , boat , top grade hotel , office building , home , cupboard broadly lieu having very good request to space , brightness , effect etc.

· Material: aluminum and PC

· Dimension: 160(L)mm*28(W)mm*8(T)mm

· Color :White/Warm White/Blue/Green/Red/Yellow

· Power supplier:DC12V/DC9.5V/DC8.2V

· Power:3W

· LED Quantity:48

· Application Environment:-20℃~45℃

· Temperature:Max.60℃

· Projecting distance:3M～10M

· Lifespan:50000hs

Item No.

Color

Power

Voltage

Λd(nm)

Tc( K )

Luminous

Drive

(constant

current)

LED

Qty.

Spec.

(mm)

Temperature

Projecting

distance

W.E.T.

Life

SP120-3W-12V-W

White

DC12V

6000K

180LM

240mA

48pcs

160(L)*28 (W)*8(T)mm

≤60℃

3～10M

-25~45°

50000h

SP120-3W-12V-WW

Warm White

DC12V

3000K

150LM

240mA

48pcs

160(L)*28 (W)*8(T)mm

≤60℃

3～10M

-25~45°

50000h

SP120-3W-12V -B

Blue

DC12V

470K

36LM

240mA

48pcs

160(L)*28 (W)*8(T)mm

≤60℃

3～10M

-25~45°

50000h

SP120-3W-12V -G

Green

DC12V

520K

150LM

240mA

48pcs

160(L)*28 (W)*8(T)mm

≤60℃

3～10M

-25~45°

50000h

SP120-3W-12V -R

Red

DC12V

625K

120LM

240mA

48pcs

160(L)*28 (W)*8(T)mm

≤60℃

3～10M

-25~45°

50000h

SP120-3W-12V -Y

Yellow

DC12V

590K

120LM

240mA

48pcs

160(L)*28 (W)*8(T)mm

≤60℃

3～10M

-25~45°

50000h

SP120-3W-9.5V-W

White

DC9.5V

6000K

180LM

320mA

48pcs

160(L)*28 (W)*8(T)mm

≤60℃

3～10M

-25~45°

50000h

SP120-3W-9.5V-WW

Warm White

DC9.5V

3000K

150LM

320mA

48pcs

160(L)*28 (W)*8(T)mm

≤60℃

3～10M

-25~45°

50000h

SP120-3W-9.5V -B

Blue

DC9.5V

470K

36LM

320mA

48pcs

160(L)*28 (W)*8(T)mm

≤60℃

3～10M

-25~45°

50000h

SP120-3W-9.5V -G

Green

DC9.5V

520K

150LM

320mA

48pcs

160(L)*28 (W)*8(T)mm

≤60℃

3～10M

-25~45°

50000h

SP120-3W-9.5V -R

Red

DC9.5V

625K

120LM

320mA

48pcs

160(L)*28 (W)*8(T)mm

≤60℃

3～10M

-25~45°

50000h

SP120-3W-9.5V -Y

Yellow

DC9.5V

590K

120LM

320mA

48pcs

160(L)*28 (W)*8(T)mm

≤60℃

3～10M

-25~45°

50000h

SP120-3W-8.2V-W

White

DC8.2V

6000k

180LM

240mA

48pcs

160(L)*28 (W)*8(T)mm

≤60℃

3～10M

-25~45°
