Shenzhen Beacon LED Co., Ltd.
China Manufacturer with main products: Indoor Full Color LED Display Screens, Outdoor Full Color LED Display, Highways VMS Displays (Traffic Guidance Signs), Advertising Displays |
Home
>Products Catalog > Indoor full color LED display series > P3.91 SMD Indoor Die-Casting Aluminum LED
P3.91 SMD Indoor Die-Casting Aluminum LED
| Supply Ability: | 5,000 Square Meter(s) per Month |
|---|---|
| Shipping: | 15 days after deposit can all details confirmed |
| Payment Terms: | L/C, T/T, Cash |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Guangdong in China |
| Packaging Details: | Indoor:Foam Outdoor:packing size depends on the screen body detailed size,usually by airfreight cas |
Quick Details
- Pixels: 3.91mm
- Display Function: Video
- Tube Chip Color: Full Color
- Usage: Indoor
- Brand Name: Beacon
- Screen Dimension: depend on customer' s request
- Display Function: Video Display
- Pixel Configuration: 1R,1G,1B
- Scanning Mode: 1/16
- Display Type: LED Video Display
- IP Rating: IP43
- LED Style: SMD2121 Black
- Module Resolution: 104X104mm
- Cabinet Materia: Die-Casting Aluminum
- Specification: CE, FCC, RoHS
- Pixel Density: 65746dots/Sq.M
Specifications
INDOOR P3.91 SMD 3IN1 TECHNICAL PARAMETERS | |||
|
Item |
Parameter | |
Model number |
WLI-P39 | ||
Module size |
250*250mm | ||
Pixel pitch |
3.91mm | ||
Pixels Density |
65336 dots/m2 | ||
Pixel configuration |
1R1G1B | ||
Package mode |
SMD2121 | ||
Pixel resolution |
64dots(W)*64dots(H) | ||
Max Power consumption |
60W | ||
Weight |
0.8kg | ||
Drive type |
Constant drive | ||
Scan mode |
1/16 scan | ||
LED Unit Module |
Dimension |
500mm*500mm | |
Quantity of Module |
4pcs | ||
Power supply |
5V/60A | ||
Pixel per cabinet |
128*128 | ||
Best viewing distance |
4m-50m | ||
Best viewing angle |
160 (W) 120 (H) | ||
Temperature |
Storage: -35C-+85C | ||
Working: -20C-+50C | |||
Operation humidity |
10%-95% | ||
Thickness |
85mm | ||
Power |
Working voltage |
AC 220V10% | |
Average Power consumption |
500W/S | ||
Max. Power consumption |
2500W/S | ||
Current |
20mA (single LED) | ||
Control system |
CPU |
Pentium 4 or above P4 | |
Operation system |
WIN98/2000/NT/XP | ||
Control method |
Synchronization | ||
Main technical |
Driving device |
Constant current | |
Refresh frequency |
400Hz | ||
Grey scale/colors |
256-levels of each color (RGB) | ||
16.7M colors | |||
MTBF |
9000 hours | ||
Power switch |
Automatic switch | ||
Display mode |
800*600/1024*768 | ||
