ZMC International Motor Corp
China Manufacturer with main products: atv, dirt bike and utility vehicles |
08' ZMC EXPLORER 500 4X4 UTV / RTV / UTILITY VEHICLE / SIDE BY SIDE
| FOB Price: | 4700.00 - 4900.00 USD/Piece |
|---|---|
| Supply Ability: | |
| Shipping: | 21 DAYS AFTER DEPOSIT |
| Payment Terms: | L/C, T/T(Bank Transfer) |
Related products from verified members
| Place of Origin: | Zhejiang in China |
|---|---|
| Packaging Details: | HEAVY DUTY PROTECTIVE PACKAGING, WITH REINFORCED FRAME AND CARDBOARD EXTERIOR. EASILY UNLOADED USING |
Specifications
ENGINE
Displacement/HP: 499cc /30 HP
Cooling: Liquid-Cooled
Engine Type: CF Moto, 4-valve4-stroke single cylinder, counterbalanced
Top Speed: 41 mph / 66 kph
Lubrication: Dry Sump
Oil Capacity: 2 qts. / 1.9 ltr.
Carburetion: 34mm Balanced
Fuel Capacity: 9.0 gal / 34.1 ltr.
Coolant Capacity: 2.3 qts. / 2.1 ltr.
Alternator: 250 watts
Starting /Battery: Electric / 12V - 30 AH
DRIVE TRAIN
Transmission: Auto - CVT (ContinuousVariable Transmission)
Gear Range: In-line, Dual-range forward and reverse
Drive: 2-wheel shaft drive electronic actuateddifferential
SUSPENSION
Front Suspension: McPherson struts with 8.0 inches / 20.3 cm oftravel
RearSuspension: Independent 9.0 inches /22.9 cm of travel
TIRES
Front: 25 x 10 - 12
Rear: 25 x 11 - 12
DIMENSIONS
Wheelbase: 76in / 193cm
Turning Radius: 148in / 376cm
Dry Weight: 1105 lbs / 502 kg
Length/Width/Height: 113x60x75in / 287x152.4x190.5cm
Foot Brakes: Dual Piston front, Single piston rear, 4-wheelhydraulic disc brakes, stainless steel lines
Parking Brake: Hand lever activated, dedicated mechanicaldisc
GroundClearance: 11 in / 27.9 cm
LOAD CAPACITY
Box Dimensions: 54x36.5x11.5 in / 137x92.7x29.2 cm
Box Volume: 13 cubic feet
Box Capacity: 1000lbs / 454kgs
Vehicle Payload Capacity: 1500lbs / 681kgs
Hitch Towing Capacity: 1500 lbs / 681 kg
ELECTRICAL
DC Outlet: Dash Receptacle
Brake Light / Taillight:Standard/Standard
Headlights: Single beam - 50w quartz halogen lights
INSTRUMENTATION
Console and other: Illuminated parking brake indicator, AWDengagement indicator, gear selection, hour meter
COLOR OPTIONS
Green, Tan Camouflage
