Sinoway Industrial (Shanghai) Co., Ltd.
China Manufacturer with main products: Road Roller, Wheel Loader, Excavator, Motor Grader, Bulldozer, Truck Crane, Mining Truck, Truck Mixer, Dump Truck, Forklift, Side Forklift... |
Hydraulic Excavator / Mini Excavator (SWE210LC)
| Shipping: | 30 days |
|---|---|
| Payment Terms: | L/C, T/T |
Related products from verified members
| Place of Origin: | Shanghai in China |
|---|
Specifications
Hydraulic Excavator / Mini Excavator (SWE210LC)
This Hydraulic Excavator has reliable performance and stable operation. Here are the specific descriptions as below:
|
Overall Dimension of Hydraulic Excavator / Mini Excavator
|
||||||
|
1
|
Length(with bucket on ground)
|
9625(mm)
|
||||
|
2
|
Width(600mm crawler shoes )
|
2980(mm)
|
||||
|
3
|
Ground length (in transportation)
|
4854(mm)
|
||||
|
4
|
Bucket width
|
1250(mm)
|
||||
|
5
|
Height(To the top of the boom)
|
2823(mm)
|
||||
|
6
|
Height(To the top of the cab)
|
2970(mm)
|
||||
|
7
|
Counter weight ground clearance
|
1107(mm)
|
||||
|
8
|
Track gauge
|
2380(mm)
|
||||
|
9
|
Tail swing radius
|
2870(mm)
|
||||
|
10
|
Min. Ground clearance
|
468(mm)
|
||||
|
11
|
Rotating platform width
|
2710(mm)
|
||||
|
12
|
Counter weight height
|
2087(mm)
|
||||
|
13
|
Crawler ground length
|
3640(mm)
|
||||
|
14
|
overall length of crawler
|
4445(mm)
|
||||
|
15
|
Crawler teeth thickness
|
26(mm)
|
||||
|
16
|
Reach from swing center to tail
|
2870(mm)
|
||||
|
17
|
Standard arm length
|
2900(mm)
|
||||
|
Main Technical Specification
|
||||||
|
1
|
Operating weight
|
20600KG
|
||||
|
2
|
Rated bucket capacity
|
0. 9 (m 3 )
|
||||
|
3
|
Max. Breakout force
|
|||||
|
|
(1)Bucket digging force
|
134KN
|
||||
|
(2)Arm crowding force
|
97KN
|
|||||
|
4
|
Max. Digging height
|
9728mm
|
||||
|
5
|
Max. Dumping clearance
|
6885(mm)
|
||||
|
6
|
Max. Digging depth
|
6611mm
|
||||
|
7
|
Max. Vertical wall digging depth
|
6030mm
|
||||
|
8
|
Max. Digging reach
|
9938(mm)
|
||||
|
9
|
Min. Front swing radius
|
2870mm
|
||||
|
10
|
Max. Pulling force
|
183KN
|
||||
|
11
|
Max. Travel speed(double modes)
|
5. 3/3. 2km/h
|
||||
|
12
|
Contact area pressure ratio
|
41. 83 KPa
|
||||
|
13
|
Pressure of system
|
32MPa
|
||||
|
14
|
Max. Grade ability
|
35°
|
||||
|
Diesel engine
|
||||||
|
1
|
Model
|
BB-6BG1TRP-02(EPA, Original ISUZU)
|
||||
|
2
|
Type
|
Water cooling . Direct injection. Turbocharged.
|
||||
|
3
|
Rated output
|
120Kw/163. 2HP @2150rpm
|
||||
|
4
|
Inter-bore of cylinder/stroke
|
105/125(mm)
|
||||
|
5
|
Total exhaust of cylinder
|
6. 5(L)
|
||||
|
7
|
Power of start motor
|
4. 5(KW)
|
||||
|
8
|
Voltage of starting motor
|
24(V)
|
||||
|
9
|
Rated speed
|
2150(r/min.)
|
||||
|
10
|
Max. Torque
|
583(N. M)
|
||||
|
11
|
Starting type
|
Electric
|
||||
|
12
|
Min. Specific fuel consumption
|
264(g/Kw. H)
|
||||
|
14
|
Net weight
|
489(Kg)
|
||||
|
Working Device Hydraulic System
|
||||||
|
1
|
Main pump (Kawasaki , import from Japan)
|
|||||
|
|
Model K3V112DT
|
Piston pump
|
||||
|
|
Max. Flow
|
210×2L/min
|
||||
|
2
|
Hydraulic motor
|
|||||
|
|
Propel hydraulic motor
|
Two axial-piston motors
|
||||
|
|
Swing hydraulic motor
|
Axial-piston motors
|
||||
|
3
|
Safety valve
|
32MPa
|
||||
|
4
|
Boom, arm and bucket circuit
|
35. 5Mpa
|
||||
|
5
|
Propel circuit
|
34Mpa
|
||||
|
6
|
Swing circuit
|
25Mpa
|
||||
|
7
|
Control circuit
|
3. 9MPa
|
||||
|
8
|
Cylinders Inter-bore × cylinder stroke × diameter of piston-rod
|
|||||
|
|
Boom cylinder
|
Ф120*1221*Ф85(mm)
|
||||
|
|
Arm cylinder
|
Ф135*1475*Ф95(mm)
|
||||
|
|
Bucket cylinder
|
Ф115*1060*Ф80(mm)
|
||||
|
Swing System (swing motor : kawasaki, M5X130CHB , import from Japan)
|
||||||
|
1
|
Drive Type
|
Hydraulic driven swing
|
||||
|
2
|
Reduction unit
|
Double row planetary gearbox
|
||||
|
3
|
Swing lubrication
|
Grease bath
|
||||
|
4
|
Swing brake
|
Multi-plate wet brake
|
||||
|
5
|
Swing speed
|
13. 5rpm
|
||||
|
Liquid coolant and lubricant
|
||||||
|
1
|
Fuel tank(diesel tank)
|
400(L)
|
||||
|
2
|
Engine oil
|
21. 5(L)
|
||||
|
3
|
Cooling System (water tank)
|
27(L)
|
||||
|
4
|
Track driver
|
5. 4(L)
|
||||
|
5
|
Swing driver
|
3. 4(L)
|
||||
|
6
|
Hydraulic oil
|
220(L)
|
||||
Remember to inform us in time if you have any question of our Hydraulic Excavator.
