Heart Technology (Shenzhen) CO. ,LTD
China Manufacturer with main products: DVR, CCTV and Accessary, Power Supplier, RFID, Access Control, Finger Scan, EM-LOCK, GPS, etc. |
Related products from verified members
| Place of Origin: | Guangdong in China |
|---|
Specifications
- Model DR1616
- Video Compression MPEG4
- Video System NTSC / PAL
- Operation System Linux, support to operate with PS2 mouse
- Simplex / Duplex / Triplex Triplex
- Video Input / Outpu BNC 16-channel inputs / 2-channel outputs
- Audio Input / Output RCA 4-channel inputs/ 2-channel output
- Display Frame Rate NTSC: 480 fps / PAL: 400 fps
- Recording Frame Rate NTSC: Max. 120 fps (CIF) or 60 fps (Half D1)
- PAL: Max. 100 fps (CIF) or 50 fps (Half D1)
- Display Resolution NTSC: 720 x 480 / PAL: 720 x 576
- Record Resolution NTSC: 720 x 240, 360 x 240
- PAL: 720 x 288, 360 x 288
- Record Mode Continuous / time schedule / motion detection / sensor triggered
- HDD Interface SATA, supports up to 500GB HDD x 2
- Playback Search Time & Date, Event List
- USB For USB Thumb drive backup & upgrading firmware / USB2.0
- PTZ Built-in RS-485 port
- Network RJ45, TCP/IP, DDNS, IE based control DVR
- Sensor & Alarm 16-channel inputs / 1-channel output
- Remote Control Included
- Power Supply DC12V, 5A (adaptor included)
- Dimension 430mm(W) x 380mm(D) x 70mm(H)
- Model DR0818
- Video Compression MPEG4
- Video System NTSC / PAL
- Operation System Linux, support to operate with PS2 mouse
- Simplex / Duplex / Triplex Triplex
- Video Input / Output BNC 8-channel inputs / 2-channel outputs
- Audio Input / Output RCA 4-channel inputs/ 2-channel output
- Display Frame Rate NTSC: 240 fps / PAL: 200 fps
- Recording Frame Rate NTSC: Max. 120 fps (CIF) or 60 fps (Half D1)
- PAL: Max. 100 fps (CIF) or 50 fps (Half D1)
- Display Resolution NTSC: 720 x 480 / PAL: 720 x 576
- Record Resolution NTSC: 720 x 240, 360 x 240
- PAL: 720 x 288, 360 x 288
- Record Mode Continuous / time schedule / motion detection / sensor triggered
- HDD Interface SATA, supports up to 500GB HDD x 2
- Playback Search Time & Date, Event List
- USB For USB Thumb drive backup & upgrading firmware / USB2.0
- PTZ Built-in RS-485 port
- Network RJ45, TCP/IP, DDNS, IE based control DVR
- Sensor & Alarm 8-channel inputs / 1-channel output
- Remote Control Included
- Power Supply DC12V, 5A (adaptor included)
- Dimension 430mm(W) x 380mm(D) x 70mm(H)
