DSC system surge production

  • ECVV Safebuy Services

    According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>

  • Safebuy Service Guarantee

    Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.


Related products from verified members

Place of Origin: Fujian in China

Specifications

 Product Description

    Current control signal surge protective device
In accordance with IEC standard design, this series SPD is special for temperature, pressure, flux DCS system (0-20mA, 4-20mA) in petroleum industry, chemical industry, steel industry, transportation, water supply etc. it adores high-quality, quick response semiconductor component protecting power and signal by one model without disrupting the signal.
   Technical parameters

  Model Protection Circuit Order No.
  TD1-13A1 Signal + Power 405 001 000 2
  TD1-13A2 Signal + Signal 406 001 000 5
  TD1-13A3 Power + Power 407 001 000 6

  Model Signal Power
  Woking type Analog data DC24V
  Application DCS System
  Rating Current (8/20/μs) In 5KA
  Max Current (8/21/μs) Isn 10KA
  Limit Voltage(1KV/μs) 0.7KA Up 4-20mA-PE:<600V 24V-PE:<600V
  4-20mA-GND:<45V 24V-0V:<45V
  Limit Voltage(8/20μs) 5KA Up 4-20mA-PE:<32V 24V-PE:<35V
  4-20mA-GND:<41V 24V-0V:<42V
  Rating Operation Current <500mA
  Insert Resistance <0.16Ω <0.36Ω
  Frequency Range 0-10MHz
  Max Transmission Speed 2Mbit/s
  Response Time <2nS
  I/O Connector Terminal Block
  Grounding Terminal Block
  Protect Circuit Signal to Signal,
Signal to GND
Power to PE,
Power to 0V

  Temperature Range -25℃ to 80℃
  Housing Materials PA66
  Degree of Protection IP20
