Shenzhen Fujikam Industry Development Co., Ltd.
China Manufacturer with main products: CCTV cameras, security system, dvr |
Related products from verified members
| Place of Origin: | Shenzhen in China |
|---|
Specifications
DVR(digital video recorder) of 16channel
1) Full screen; A quarter screen; 16th photos screen.
2) Record modes: Manual record, time record, alarm record, mobile detection record
3) Resolution, photo quality level, frame are adjusted individually.
4) Search mode: Search according to the time and record files (alarm, protocol detection)
5) Operation is network, record, playback at the same time
6) Network function is Remote monitor, remote playback, remote record, remote control, remote menu setting and backup the statistic to the PC hard disc
7) Support: Support DDNS, PPPoE protocol; Connect the outside internet with the mobile IP address.
8) Support: Support several persons monitor online (at most 5 person)
9) Backup: Can download from the client' s network, through USB2.0 to connect the store equipment (mobile hard disc, USB, )
10) Support: Support PTZ presets and auto cruise
11) Support: Management, lock, deletes the record files.
12) Support: Support network double data rate, support quick connection to the internet.
13) Support: USB mouse to control
14) Support: Support daily inquire, clients purview distributed management.
15) Support: Support IE browser and local keyboard operation.
16) Support: Support VGA output, connect the monitor directly.
16) Support: 8 pieces SATA hard disc (500G)
17) Support: Record for a longer time with the low data rate.
18) real time live display for all camera
19) multi-level password protection
20) minimum 16 frame per second
21) RS232/RS485/RJ45 input
22)remote cotrol options available.
| item |
FI-1316ATP |
| Video compression |
H.264 / MPEG-4 (optional) |
| Picture pixel |
PAL:704*576 NTSC: 704*480 |
| Playback resolution |
CIF/Half D1 |
| Video Input |
16CH |
| Video Output |
4 CH |
| Recording Frame |
PAL: 16 -25F /S/CH NTSC: 16 -30F /S/CH |
| Alarm Input |
16CH |
| Alarm Output |
4 CH |
| Resolution |
display(704 X 576) VGA output (1024 X 768/60HZ) or (800 X600/75Hz), (800 X600/60Hz), Video compression CIF(352 X 288), Ha 1f DI (704 X 288) |
| Recording resolution |
CIF, Half DI |
| Recording Picture Quality |
6 levels(l,2,3,4,5,6 ) 1 is best |
| Support |
Support 8pc HDD |
| Back-up |
SATA or IDE HDD, Network |
| the connector |
RS485,Alarm input and output |
| network connector |
lOM/I 00M (Ethemet network port) |
| Dimension |
90mm * 441mm * 470mm |
| Power |
90-135VAC or 180-265VAC |
| Power consumption |
20-42W |
| USB interface |
1piece |
| Mouse interface |
1 piece |
| Keyboard interface |
1 piece |
| Support HDD |
500 G |
| language menu |
English(optional) |
