Baoji Toptech Industrial Co., Ltd.
China Manufacturer with main products: Metal Detector, Needle Detector, Detector Metal, Check Weigher, Needle Detection Machine, X Ray Detector, Titanium, Titanium Tube |
Home
>Products Catalog > Auto conveyor check weigher for auto weight sorting > New High Speed Conveyor Check Weigher 220S Weight Sorting Machine
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Shanghai in China |
| Packaging Details: | Wooden case |
Quick Details
- After-sales Service Provided: Overseas third-party support available
- Type: Cooking Equipment
- Brand Name: JL-CW
- Voltage: 220v
- Condition: NEW
- Model Number: 220S
- model: auto conveyor check weigher
- belt width: 220mm
- Name: check weigher
Specifications
1.Features:
(1). at high weight sorting Accuracy and high speed rejection system
(2). Strong stainless steel Structure; Water proof design
(3). High accurate loadcell; Based on advanced DSP technology
(4). Automatic weighing Compensation and zero tracking
(5). 100 products preset; easy to Edit and recall
(6). Quickly products shift and Speed recall
(7). Memory support 2000 sorting Records stored:
(8). Install USB port and RS 232,it Support data,record output and print
(9). Fast reject system can remove Out less or over weight products automatically
(10). 10'' Touch screen,friendly and simple operation interface with English language
(11). Support different password setting for admin and operation authority.
(12). Made of 304 stainless Steel, fairly dustproof, waterproof. Easy to be cleared.
2. Parameters
Model |
CW-220 |
| ||
Weight Range |
51000g |
| ||
Accuracy |
±0.5g (Depend on conveyor speed) |
| ||
| ||||
Conveyor Model |
Flat PU Belt(Belt width:220mm) |
| ||
Auto Reject |
Auto Pusher/Auto Air jet rejection |
| ||
Reject Air pressure |
0.5MPA | |||
LCD Display |
English |
| ||
Mini Scale |
0.1g |
| ||
Conveyor Speed |
25-85m/minutes(adjustable) |
| ||
Product Memory |
Support 100 sets product parameters |
| ||
Sorting Memory |
Support 2000 sorting records. |
| ||
Frame Material |
SUS304 polish process |
| ||
Meas |
L x W |
1200mm x 700mm |
| |
Conveyor Belt height |
800±100mm |
| ||
Data&record Output |
USB port&RS232 |
| ||
Weight |
App 120Kg |
| ||
Power |
Single AC220V 50Hz |
| ||
Others Parts |
Plexiglass cover / Feed guider / Auto Reject, / Alarm pilot light |
| ||
