JAC Mounted Crane Truck

Shipping:	30-40days
Payment Terms:	L/C, T/T(Bank Transfer)

Inquiry Now

Related products from verified members

Mobile Crane Hidrokon HK 90 L6

Price:102,125.00 USD/Unit

Min. Order:1 Unit

Product Details

Place of Origin:	Shanghai in China

Specifications

JAC Derrick Truck
Cargo Truck
Mounted Crane Truck

Drive: 4*2/6*2/6*4/8*4

Engine:
1. Engine Displacement: 3856cc/4752cc/9726cc/9839cc/12000cc

CY4102BZLQ 120HP CA6DF2D-19 190HP YC6J190-20 190HP CA6110/125Z1A1 180HP
YC6J180-21 180HP CA6DF2D-16 160HP CA6DF2D-22 220HP 6C240-2 240HP
CA6DF2-24 240HP CA6DF2-26 260HP WD615.56 260HP
YC6M280-20 280HP WD615.50 290HP WD615.31 310HP
WD615.44 330HP WD12.336 336HP WD12.375 375HP
YC6M320-20 320HP WD615.46 360HP

CRANE PART:

SQ66H
Maximum lifting capacity of crane
3000kg
Maximum lifting Moment
66kN. M
Maximum extend rang
5.9m

Maximum high lifting height
9m
The span of outrigger
2.33.2m
The Quality of Crane
1200kg

Maximum lifting capacity of crane
3000kg
Maximum lifting Moment
73kN. M
Maximum extend rang
7.45m

SQ73
Maximum high lifting height
9.8m
The span of outrigger
24m manually operation
The Quality of Crane
1300kg

SQ20H
Maximum lifting capacity of crane
1500kg
Maximum lifting Moment
31.5kN. M
Maximum extend rang
4.45m

Maximum high lifting height
7.2m
The span of outrigger
1.82.85m manually operation
The Quality of Crane
1050kg

SQ112-2
Maximum lifting capacity of crane
5000kg
Maximum lifting Moment
112kN. M
Maximum extend rang
9m

Maximum high lifting height
10.5m
The span of outrigger
2.285.08m Hydraulic

The Quality of Crane
2000kg

SQ112A
Maximum lifting capacity of crane
5000kg
Maximum lifting Moment
125kN. M
Maximum extend rang
12m

Maximum high lifting height
14m
The span of outrigger
2.285.08m Hydraulic

The Quality of Crane
2300kg

SQ141-1
Maximum lifting capacity of crane
6300kg
Maximum lifting Moment
138.9kN. M
Maximum extend rang
12m

Maximum high lifting height
14m
The span of outrigger
2.285.08m Hydraulic

The Quality of Crane
3045kg

Maximum lifting capacity of crane
6300kg
Maximum lifting Moment
141kN. M
Maximum extend rang
9m

Maximum high lifting height
10.5m
The span of outrigger
2.285.08m Hydraulic
The Quality of Crane
2300kg

SQ200-3
Maximum lifting capacity of crane
8000kg
Maximum lifting Moment
200kN. M
Maximum extend rang
10.5m

Maximum high lifting height
13.79m
The span of outrigger
2.285.10m Hydraulic
The Quality of Crane
2800kg

SQ240
Maximum lifting capacity of crane
8000kg
Maximum lifting Moment
240kN. M
Maximum extend rang
13.3m

Maximum high lifting height
15m
The span of outrigger
2.325.39m Hydraulic
The Quality of Crane
3640kg

SQ300
Maximum lifting capacity of crane
10000kg
Maximum lifting Moment
300kN. M
Maximum extend rang
13.3m

Maximum high lifting height
15.1m
The span of outrigger
2.325.4m Hydraulic
The Quality of Crane
3700kg

SQ320
Maximum lifting capacity of crane
12000kg
Maximum lifting Moment
320kN. M
Maximum extend rang
13m

Maximum high lifting height
16m
The span of outrigger
2.285.9m Hydraulic
The Quality of Crane
4500kg

SQ115H
Maximum lifting capacity of crane
5000kg
Maximum lifting Moment
115kN. M
Maximum extend rang
7.7m

Maximum high lifting height
10.8m
The span of outrigger
2.263.9m manually operation
The Quality of Crane
1800kg

SQ186H
Maximum lifting capacity of crane
8000kg
Maximum lifting Moment
186kN. M
Maximum extend rang
7.9m

Maximum high lifting height
10.7m
The span of outrigger
2.325.4m manually operation
The Quality of Crane
2100kg

SQ300H
Maximum lifting capacity of crane
12000kg
Maximum lifting Moment
300kN. M
Maximum extend rang
12.2m

Maximum high lifting height
14.3m
The span of outrigger
2.286m Hydraulic

The Quality of Crane
4850kg

SQ450H
Maximum lifting capacity of crane
20000kg
Maximum lifting Moment
450kN. M
Maximum extend rang
12 m
