Product Details

Place of Origin:	Shanghai in China

Specifications

Categories:	Rotary encoder->Absolute value-solid shaft->SJ65
product number:	SJ65-C
product name:	SJ65-C series (absolute value)

■ Absolute value: (solid shaft)
● External dimensions：small volume, external diameter: ?65mm, thickness: 52mm, shaft diameter: ?10mm (D type mouth)
● Resolution：attainability:10bit(1024)
● Output：gray code without read error
● Power voltage:DC12V-24V
● Grade of Protection: IP65
● Plug: 13 core
● Material of outer cover: aluminum
● Weight: about 260g
