Product Details

Place of Origin:	Shandong in China

Specifications

Small Wind Power Generator Specifications
Product Name	300W Full Permanent Magnetic Suspension Wind Power Generator	350W New-type Horizontal Wind Power Generator	400W Wind Power Generator	600W Wind Power Generator	1KW Wind Power Generator
Part Number	DN1.5-0.3/10C	DN1.5-0.35/12	DN1.2-0.40/12	DN1.9-0.6/11	DN2.7-1.0/12
Rated Power	300W	350W	400W	600W	1KW
Starting Wind Speed (m/s)	1.8m/s	2.0m/s	3.0m/s	2.0m/s	3.0m/s
Cut in Wind Speed (m/s)	2.5m/s	2.8m/s	3.0m/s	2.8m/s	3.0m/s
Rated Wind Speed (m/s)	10m/s	12m/s	12.5 m/s	11m/s	12m/s
Safe Wind Speed limited (m/s)	50m/s	50m/s	50m/s	50m/s	50m/s
Rated DC Output	12V/24V	12V/24V	12V/24V	24V	24V/48V
Over-speed protection	Electro-magnetic torque control	Electro-magnetic torque control	Electro-magnetic torque control	Electro-magnetic torque control	Passive Side Furling
Color	White	White	White	White	White
Net Weight	20kg	17kg	6kg	22kg	45kg
Gross Weight	23kg	21kg	7kg	26kg	64kg
Bearing using	Full Permanent Magnetic Suspension Bearing	Mechanical Bearing	Mechanical Bearing	Mechanical Bearing	Mechanical Bearing
Application Ratio (Cp)	0.42	0.4	0.38	0.4	0.4
Number of blades	3	3	3	3	3
Blades Material	Reinforced Nylon	Reinforced Nylon	Reinforced Nylon	Reinforced Nylon	Nylon + Fiber Glass
Rotor Rotor Diameter	1.5m	1.5m	1.2m	1.9m	2.7m
Length of Body	1220mm	1190mm	700mm	1420mm	2300mm
Pictures of Wind Gnerators	Bitmap	Bitmap	Bitmap	Bitmap	Bitmap
Life Span	15years -20years	15years -20years	15years -20years	15years -20years	15years -20years
Customer Servise	The entire Lifespan	The entire Lifespan	The entire Lifespan	The entire Lifespan	The entire Lifespan
Warranty	1st year	1st year	1st year	1st year	1st year
