Dalian Teren Industry Instruments Import & Export Co., Ltd.
China Manufacturer with main products: Ultrasonic Level Meters, Ultrasonic Water Meters, Gas Meters, Ultrasonic Thickness Meters |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Liaoning in China |
Specifications
TECHNOLOGICAL SPECIFICATION:
RANGE: HLT4: 4.00m(Liquid)
HLT6: 6.00m
HLT8: 8.00m
BLANKING DISTANCE: HLT4: 0.20m
HLT6: 0.25m
HLT8: 0.30m
Accuracy(In air): 0.2%Full Span
Output Current: 4~20mA
Output Load: 0~500Ω
Output Resolution Ratio: 0.03% full span
Parameter Set Up: 3 induction buttons
Temperature Range: -40oC~80oC
Temperature Compensation: The whole range is automatic
Pressure Range: ±0.1MP (press definitely)
Power Supply: DC24V ±20% 30mA
Cable Diameter: F6~F12mm
Single Wire Diameter: F0.5~F1.78mm
Cable Fix: PG13.5
Beam Angle: 8o(3db) Measuring Range 4m 6m 8m 5o(3db)
Measuring Range 8m(A) 10m 15m 20m 30m
Measure Cycle: 1 second
Crust Material: ABS
Sensor Material: PVC
Protect Grade: IP67
Mode Installation: Flange or the support
Fange Standard of Butt Joint: Measuring range 4m 6m 8m:Minimum DN65
Ultr-liquid from this supplier
FOB Price: 3000.00-5000.00 USD/Unit
Min Order: 1 Unit
