China capacitor Green CO.,LTD
China Manufacturer with main products: ac motor capacitor, motor capacitor, start capacitor, film capacitor |
Motor Running Capacitor
| FOB Price: | 0.35 - 0.86 USD/Piece |
|---|---|
| Shipping: | 15 days |
| Payment Terms: | T/T(Bank Transfer) |
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
Related products from verified members
| Place of Origin: | Anhui in China |
|---|---|
| Packaging Details: | 200 pcs/carton |
Specifications
Name:CBB61 A.C.
Item:CBB61 A.C.
Description:Description:
CBB61 A.C. Metalized Polypropylene Capacitor
CONSTRUCTION: non-inductive wound metallized polypropylene
COATING: flame retardant plastic case with resin seal
RATED VOLTAGE: 180VAC----500VAC(250V/370V/400V/440V/450V/500V)
LIFE EXPECTANCY: CLASS B-10.000h/CLASS C-3,000h
RATED FREQUENCY: 50/60Hz
RATED CAPACITANCE: 1μF---14μF
CAPACITANCE TOL.: ±5%, ±10% (standard), other tolerances upon request
CLIMATIC CATEGORY: 40/85/21 (IEC 60252)
OPERATING TEMP. RANGE: -40/+85°C
CASE: Plastic
TEST VOLTAGE TERMINAL TO TERMINAL: 2 x Un for 60s (Un: rated voltage)
TEST VOLTAGE TERMINAL TO CASE: 2000VAC for 60s
SAFETY CLASS:P0/P2
MAX. PERMISSIBLE VOLTAGE(RMS): 1,1 x Un
MAX. PERMISSIBLE CURRENT(RMS): 1,3 x In
MAX. PERMISSIBLE REACTIVE OUTPUT: 1,35 x Qn
Approvals: UL,VDE,TUV,CSA,CQC
