Shanghai Long Zhen Heavy Industry Co., Ltd.
China Manufacturer with main products: Crusher, Sand Making Machine, Sand Feeding Machine, Sand Washing Machine |
Impact Crusher
| Supply Ability: | 100 Set/Sets per Month |
|---|---|
| Shipping: | 30 days |
| Payment Terms: | L/C, T/T(Bank Transfer) |
Related products from verified members
| Place of Origin: | Shanghai in China |
|---|---|
| Packaging Details: | According to export standard |
Specifications
Product Information
Impact Crusher absorbing domestic and foreign technology and optimizing design, can process the granite, basalt and limestone materials with the input size of 120-350mm and the hardness below 320MPa.
It has the characteristics of big crushing rate, high crushing efficiency and easy maintenance etc.
The high content of the cubic forms and low chip forms make it be the best choice of the equipment for the high way, railway, irrigation, airport architect industry and so on.
Advantages and characteristics
Short toggle
Crushing hard rock
Connection with locking sleeve assembly
The blow bar with high chrome
Hydraulic or hand openrea switch
Impact plate with special shape
Crushing hard rock
Connection with locking sleeve assembly
The blow bar with high chrome
Hydraulic or hand openrea switch
Impact plate with special shape
- Impact crusher Operating principle:
Impact crusher is made up of rear case, rotor rack, hammer, impact rack, and frame. The rotor of impact crusher, equipped with hard hammers, rotates at high speed. The materials will firstly enter into the first crushing area where the hammer of the rotor will directly crush and throw the materials up to the first impact cavity which has many tough impact plates. Thanks to the shock of impact rack, the materials will fall on the hammer again and be crushed. This action will be done consistently till the materials are crushed to the suitable size and then are discharged through the discharging opening.
The space between rotor and impact rack can be adjusted in order to changing the crushing degree and the end product’s shape.
- Thanks to the knocking work principle of impact crusher, the final product is with perfect shape (cubical and with several edges).
Main technical parameters
| Model | Spec of Rotor (mm) |
Feed Opening Size (mm×mm) |
Max. Feed Edge (mm) |
Processing Capacity (t/h) |
Motor Power (kw) |
Weight (t) |
Overall Dimensions (L×W×H)(mm) |
|---|---|---|---|---|---|---|---|
| PF-1007 | φ1000×700 | 400×730 | 300 | 37-45 | 30-55 | 9.5 | 2400×1558×2660 |
| PF-1010 | φ1000×1050 | 400×1080 | 350 | 50-80 | 55-75 | 12.2 | 2400×2250×2620 |
| PF-1210 | φ1250×1050 | 400×1080 | 350 | 70-120 | 110-132 | 14.1 | 2690×2338×2890 |
| PF-1214 | φ1250×1400 | 400×1430 | 350 | 130-180 | 132-160 | 18.6 | 2690×2688×2890 |
| PF-1214 | φ1250×1400 | 400×1430 | 350 | 130-180 | 132-160 | 19.2 | 2690×2688×2890 |
| PF-1310V | φ1300×1050 | 490×1170 | 350 | 70-120 | 110-160 | 13.5 | 2780×2478×2855 |
| PF-1315V | φ1320×1500 | 860×1520 | 350 | 150-220 | 180-220 | 20.5 | 3096×3273×2667 |
| PF-1515V | φ1500×1500 | 850×1580 | 350 | 220-280 | 280 | 29.5 | 3550×2835×3280 |
| PFX-1010 | φ1000×1500 | 400×1080 | 40 | 20-50 | 90-110 | 9.2 | 2492×1821×2202 |
