LED Wallwasher (YK-TGD012WH009)

Supply Ability:	10,000 Piece/Pieces per Week
Shipping:	7~14 days
Payment Terms:	L/C, T/T(Bank Transfer)

Inquiry Now

Related products from verified members

LED Wall Washer

Price:

Min. Order:
Wall Washer Light

Price:

Min. Order:100 Sets
LED Wall Washer

Price:

Min. Order:
Waterproof 48W Aluminum Alloy LED RGB Wall Lamp...

Price:1.00 USD/Piece

Min. Order:100 Pieces

Product Details

Packaging Details:	cartons

Specifications

Product Features： The use of high-strength shell of aluminum die-casting，With good heat dissipation, the characteristics of beautiful shape。American imports of light chip beads，Has a high luminous intensity, energy saving, long-life, environmental protection, job security and so on.
Product use： Landscape lighting, city lighting engineering, stage lighting, architectural lighting, advertising lighting, etc.
Product Appearance Description	1,Size：	L280×W210×H165mm
	2,Material：	Die-casting aluminum shell, toughened glass
	3,Color：	Silvery white,Black
	4,Surface Treatment：	Paint
	5,Connector type：	DMX512
Parameters Of Electrical products	1,Power:	12×1W
	2,LED　Quantity :	Monochromatic：12PCS RGB：R×4,G×4,B×4
	3,InputVoltage：	AC100～240V
	4,Light-emitting angle：	15°,30°,45°
	5,Luminous flux of each LED Red:　40～50Lm　　Yellow:　40～50Lm　　 Blue:　15～20Lm　　Green:　60～70Lm　 White:　70～80Lm/80～90Lm/90～100Lm/100～120Lm WarmWhite:　55～65Lm/65～75Lm/75～90Lm/90～100Lm
	6,Lamp’S Efficiency：	﹥95％
	7,Color temperature： Red:620～630nm　　　　Yellow:588～593nm　 Blue:460～470nm　　　　Green:520～530nm　 White:6000～7000K　　WarmWhite:2700～3300K
	8,Chip Voltage： Red/Yellow: 2.0～2.5VDC Blue/Green/White/WarmWhite: 3.0～3.6VDC
	9,Chip Current: Red/Yellow: 400mA Blue/Green/White/WarmWhite: 350mA
	10,Frequency Range：	50～60Hz
	11,Power Factor(PF)：	﹥90％
	12,Color Index(CRI)：	Ra＞80
	13,Junction Temperature(Tj)：	60 ° C ± 1 0% ( Ta= 25 ° C )
	14,Working Temperature：	- 30 ° C ~ 40 ° C
	15,Working Humidity：	10 % ~ 90 % RH
	16,Working Life：	30,000 Hrs
	17,Projection distance	≧10M
	18,Control Mode	Built-in constant current driver / control changes in full-color / DMX512 control
	19,Changes in the effect ：	Water, RGB full color change, 256RGB gray-level
	20,Protection level	IP68
Packaging	1,White box packaging 2,White box size: 3,Weight: 4,Carton size： 5,Each containing： 6,Gross weight：
Remark： Customers can customize the package size and appearance
