| Place of Origin: | Fujian in China |
|---|
Specifications
Ascendant capability
1,It’s single rocking arms and six-bar linkage have powerful digging force and high effectiveness;
2,Schistic front frame of CAT type, double beam box-section structured rear frame, ensures maximum stability, rigidity and intensity.
3,Adopt articulated frame, has smaller turning radius, moving around more flexible, meet all requirements of all working situations.
4,Hydro-mechanical transmission system is well matched so it has enough traction during work.
5,Hydraulic slip is very little, improve thermal equilibrium and increase hydraulic element’s service life.
a,Provide a full hydraulic pressure sensing redirector, steering behavior is perfect in Hi-lo speed .It has straight driving performance, flexible to be operated.
b,Working hydraulic system with simultaneous flowing dual pumps, cut back oil wear and energy wear significantly.
6,Outfit with four stroke, six cylinder supercharged engine such as WD615G-220,D9-220 or C6121ZG,and axle & transmission made by Jiande, which can works in poor environment.
Specifications
Engine
Rated power (kw)
162KW
Overall dimensions
Length× Weight× Height(mm)
7835×3040×3340（mm）
(8000×3040×3340)
Dump clearance(mm)
≥2900 mm(3220)
Distance acc. to the height(mm)
≥1050 mm(1130 )
Specification of type
23.5-25(16)PR
Performance parameters of entire machine
Operating weight (t)
16.1t
Rated Bucket capacity(m3)
2.7m3
Rated load(t)
5t
Max. digging force(KN)
140KN
Max. pull(kn)
140KN
Turn angle(。)
±35o
Loader clearance radius(mm)
≤7025 mm(7110)
Transmission
KEN TAK ZL40.50A
No. of shifts(forward/reverse)
2/1
Fuel tank(L)
275L
Hydraulic system(L)
220L
Time of Raise(s)
≤7.0S
Hydraulic cycle time(s)
≤13.0S
Driving Speed
Forward 1st gear (km/h)
11.5km/h
Forward 2nd gear(km/h)
36km/h
Reverse 1st gear(km/h) 16km/h
Reverse 2nd gear (km/h)
Note: Figures in brackets denote the size of KT852-II wheel loader.
Optional Parts
WD615G-220,D9-220,C6121ZG Heater,Air conditioning（well-being）Electric fans,AM\FM Radio GPS Satellite navigation
