CCTV Multiplexer

Inquiry Now

Place of Origin:	China

Specifications

9 CH Quad Processor

Features

Adopt international brand chip; Make super stable, high definition, full digital processing, new generation Quad Processor with remote.

Four pictures real time display, eight pictures non-real time display, with video moving detection alarm ,image loss alarm functions,auto.

Enabled in multiple picture display modes.

Compatible PAL/NTSC system, blue grounding screen.

Single picture amplifying and partial picture amplifying functions.

Technology specification

Items	BG-812D/BG-813D/BG-815D/BG-816D
Video signal	PAL / NTSC
Refresh rate	50 fields/sec (PAL). 60 fields/sec (NTSC)
Definition	720×576 (PAL). 720×480(NTSC)
Video input	8×BNC. 1.0V_P-P.75Ω
Record input	1×BNC. 1.0V_P-P.75Ω
Monitor output	1×BNC. 1.0V_P-P.75Ω
Video output modes	single picture, two pictures, picture in picture, picture out of picture, four pictures, eight pictures and switched automatically.
Dimension	BG-812D: 220L×220W×45Hmm BG-813D: 295L×210W×45Hmm BG-815D: 295L×210W×45Hmm BG-816D: 260L×190W×48Hmm
Power source	DC 12V/1A.
