Repeater (W33-GD)

FOB Price:	1000.00 - 10000.00 USD/Piece
Payment Terms:	T/T(Bank Transfer)

In Stock

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Product Details

Place of Origin:	Guangdong in China
Packaging Details:	standard

Specifications

Electrical Specification
Frequency Range
     CDMA                      UL:824~849MHz       DL:869~894MHz
     GSM850                  UL:824~849MHz       DL:869~894MHz
     GSM                        UL:880~915MHz       DL:925~960MHz
     DCS                         UL:1710~1785MHz   DL:1805~1880MHz
     PCS                         UL:1850~1910MHz   DL:1930~1990MHz
     WCDMA                   UL:1920~1980MHz   DL:2110~2170MHz
Bandwidth                        Bandwidth is available upon request
Maximum Gain                                         83dB
Manual Gain Control                         31dB@1dB/Step
Auto Level Control                                    20 dB
Output Power                                          33dBm
Spurious Emission                    -36dBm (9KHz~1GHz)
                                                  -30dBm (1GHz~12.75GHz)
Noise Figure                                             6dB(Typical)
Return Loss                                              -14dB
Group Delay                                            5us
