Product Details

Place of Origin:	Zhejiang in China

Specifications

SPECIFICATION    EPA, CARB ,EEC approved
EEC and EPA APPROVED
Engine:
Type: 2 cylinders,4-stroke,liquid-cooled
Bore x stroke: 76mm x 71mm
Displacement: 644cc
Compression ratio: 8.4:1
Carburetor: BJH101E
Max. power: 20.6kW/5,300rpm
Maximum torque: 44/2,700~3,300N.m/r/min
Starting: electric
Ignition: CDI
Lubrication: force and splash
Transmission: manual clutch,4-shift/reverse
Spark plug: F6T or F6TC
Fuel type: RQ93 (unleaded)
Lubricate oil: SAE-15W/30

Capacities:
Turning radius: 157.5" (4,000mm)
Fuel tank: 30.0L
Engine oil: 2,900ml
Coolant: 4,000ml
Starting: <5s
Climbing: 20"- 25''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''
Battery: 12V,52Ah
Head light: 12V,80W/both
Tail light: 12V 52W/both
Fuse: 35A
Max. speed: 35 miles/h
Max. load capacity: 400kg

Chassis:
Brake: hydraulic disc both on front and rear,right foot control
Front tire: 25x10-12
Rear tire: 25x10-12
Suspension: independent dual A-arm both front and rear
Drive train: 2WD/4WD shaft controllable

Dimension
Overall length: 116in. (2,950mm)
Overall width: 62in. (1,580mm)
Overall height: 72in. (1,830mm)
Wheelbase: 78in. (1,990mm)
Front track: 48in. (1,220mm)
Rear track:47in.(1.200mm)
Ground clearance: 11.6in. (295mm)

Conveyance
shpping info:6pcs(20'''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''''')/14pcs(40HQ)
N.W./G.W.:565kg /615kg
