glass magnesium board production line


Related products from verified members

Place of Origin: Hebei in China

Specifications

   Glass magnesium fireproofing board is called glass magnesium board for short. Glass magnesium board is based on magnesium oxide, magnesium chloride, water and processing modifier configured and stable performance of magnesia made of cementitious materials, and then adding sawdust (rice paper), perlite, non-woven fabrics, glass cloth composite materials by the use of special processing from the production of a new type of non-flame decorative materials.

Glass magnesium board with fire retardant , fire-resistant moisture-proof, light insulation, noise insulation, non-toxic tasteless, non-sp does not rot and etc characteristics.glass magnesium board is green environmental protection, high strength, toughness and long service life and construction of simplewhich can be cut,planed and can nail and bent, can be sprayed directly on the one hand, prominent features such as wallpaper paste.
   The use of the product also has a wide range of architectural decoration in the field can be used both inside and outside the walls, smallpox ceiling, hotels fixed desk frame, office screen, ventilation pipe, building templates and so on.glass magnesium board can also be used to separate the fire resistance panels, various types of fire doors and a firewall is an ideal substitute for various sheet products.glass magnesium board is the focus of the recommended green building materials by National Building Decoration Association.
The process of glass magnesium board:
   1、Preparation:magnesium oxide, magnesium chloride, perlite, non-woven fabric, glass cloth, sawdust, water through quantitative measures placed into raw materials in the slurry mixer.
   2、Forming transmission: non-woven fabric, glass cloth into the machine after open-book, mold in the forming machine platform has been placed back-up, mixer into the slurry into the molds on the forming machine, extrusion forming machine in the requirements specification glass magnesium board and then cut the length required by the horizontal transfer system, distribution of oxygen into the oxidation chamber for retaining.
   3、 Dehalogenation: put glass magnesium board which have been oxidized into the water immersion and add dehalogenation to deal with.
   4、Trimming: after glass magnesium board dehalogenated and then through automatic trimming machine to complete the glass magnesium board of fixed-length trimming, packaging and stacking.stacking after the completion of the use of forklift trucks transported to the packing area test packaging, to complete a full set of production line processes. Upon completion of the use of forklift stacking transported to the packing area test packaging.The process of the full set of production line is completed.
The main characteristics of glass magnesium board production line of Shijiazhuang Lvsheng Machinery Co,.Ltd
   1、 Structure and specifications  The use of triangle material,reasonable structure,running smooth,uniform thickness and high yield, To do with non-woven separation membrane which can enhance the toughness and strength. This production line can produce sheet of 2440mm*1220mm,thickness between 6-15mm and the thickness of glass magnesium board can be arbitrarily adjusted.
   2、Thickness: In normal circumstances, the production of 6mm-15mm thickness glass magnesium board and can guarantee the quality and accuracy.
   3、This is one set of traditional equipment and there need about 16 workers
    4、The low-cost equipment, low investment and quick returns.
  Our company can supply full complete set of service according to customers desire,from the machine design,working room design ,produce, installation and commissioning,old line modification  until produce the qualified products.
