Smarteam Technology Ltd.
China Manufacturer with main products: Thru Hole Soldering Station, Thru Hole Desoldering Station, Thru Hole Selective Soldering and Desoldering Station |
through Hole Components Soldering & Desoldering
| Shipping: | 2 Months |
|---|---|
| Payment Terms: | L/C, T/T(Bank Transfer), Cash |
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
Related products from verified members
| Place of Origin: | Beijing in China |
|---|
Specifications
| Specification | |
| Application | All through-hole component as IC, transform, connector, and so on. |
| Soldering process | Lead or lead free |
| Soldering process | Two modules, manual control or automatic program control. One solder process can be divided into different section of soldering with different height and last time. Can be programmed one wave soldering and two times soldering like double wave soldering. |
| Soldering peak height | 0 to 10 mm above nuzzle, programmable |
| Solder pump | Propeller driven by servo motor |
| Lead free pump | Made by titanium (Optional) |
| Control unit | PLC of Siements, LCD display of the parameter, small key board as operate panel, foot switch |
| Soldering peak high | Programmable controlled by PLC |
| Soldering wave up speed | Programmable |
| Soldering wave down speed | Programmable |
| Soldering time | Programmable |
| Soldering temperature | PID close loop control by PLC Max. 380 Celsius |
| Standard nuzzle | (Optional) |
| Special nuzzle | Customer request design(Optional). Some nuzzle can be used to soldering desoldering two component in different position of the board by one time soldering process. |
| Air solders cleaning | Used to cleaning the solder dross left in the hole after take off the component |
| Standard air nuzzle | (Optional) |
| Special air nuzzle | Customer request design (Optional) |
| Protection | Temperature high limitation set by programmer |
| Heater | Electricity, Max 1,200 w |
| Material | Stainless steel |
| Board holder | Slide movement by rail manual |
| PCB max. | 600 x 500 mm |
| Component length | Max. 220 mm |
| Board holder shift | 400 mm to left |
| Board holder height | Max. 25mm adjustable manual |
| Size | Width 490 Height 360 Deep 720mm |
| Weight | 40 kg |
| Color | Blue and White, or at request |
| Solder pot capacity | 16 kg |
| Power supply | 220 V |
| Working environment | Above 20 degree Celsius |
| Pls contact me freely for further discuss and more information! | |
