Qiaoshi Fence Post Factory
China Manufacturer with main products: t post, fence post, y post, star picket, field fence, barbed wire, post clips, post anchor |
Barbed Wire
| FOB Price: | 600.00 - 800.00 USD/Ton |
|---|---|
| Supply Ability: | 20 Ton per Day |
| Shipping: | ACCORDING TO DIFFERENT ORDER, MOSTLY WITHIN ONE MONTH |
| Payment Terms: | L/C, T/T(Bank Transfer), D/A, D/P, Western Union, PayPal, in cash |
| Place of Origin: | Hebei in China |
|---|---|
| Packaging Details: | PACKAGED IN BARBED WIRE COIL, BARBED WIRE MESH, BARBED WIRE STRAND |
Specifications
Galvanized Barbed wire
Galvanized Barbed Iron Wire in QS-3 type has 2 strands and 4 points. Barbs' distance can be 3-6 inches with a tolerance at 1/2" less or more.
Galvanized Barbed Iron Wire in QS-3 type has 2 strands and 4 points. Barbs' distance can be 3-6 inches with a tolerance at 1/2" less or more.
Galvanized Barbed Wire is suitable for industry, agriculture, animal husbandry, dwelling house, plantation or fencing.
1. Patterns Available for Galvanized Barbed Wire:
Single Twisted Barbed Wire
Double Twisted Barbed Wire
Traditional Twisted Barbed Wire
Single Twisted Barbed Wire
Double Twisted Barbed Wire
Traditional Twisted Barbed Wire
2. Features: Galvanized barbed wire offers a great protection against corrosion and oxidation caused by the atmosphere. Its high resistance allows greater spacing between the fencing posts.
3. Packing: In coils.
PVC Coated Barbed Wire
We offer plastic coated barbed wire in different colors, mostly green coated.
We offer plastic coated barbed wire in different colors, mostly green coated.
Technical Info of PVC Coated Barbed Iron Wire:
Core of PVC Coated Barbed Iron Wire can be galvanized iron wire or black annealed iron wire.
Colors: A variety of colors like green, blue, yellow, orange, gray, is available with PVC Coated Barbed Iron Wire produced by us.
Tensile strength of Standard PVC Coated Barbed Iron Wire is 30-45 kgs./sq.mm.
Packing: In coil of 25 kilos or 50 kilos net, lined with P.V.C strips, then wrapped with P.V.C or hessian cloth.
Core of PVC Coated Barbed Iron Wire can be galvanized iron wire or black annealed iron wire.
Colors: A variety of colors like green, blue, yellow, orange, gray, is available with PVC Coated Barbed Iron Wire produced by us.
Tensile strength of Standard PVC Coated Barbed Iron Wire is 30-45 kgs./sq.mm.
Packing: In coil of 25 kilos or 50 kilos net, lined with P.V.C strips, then wrapped with P.V.C or hessian cloth.
Standard Specification of Barbed Wire
|
Gauge of Strand and Barb in B.W.G. |
Approximate Length per Kilo in Meter | |||
|
Barbs Spacing 3" |
Barbs Spacing 4" |
Barbs Spacing 5" |
Barbs Spacing 6" | |
|
12x12 |
6.0617 |
6.7590 |
7.2700 |
7.6376 |
|
12x14 |
7.3335 |
7.9051 |
8.3015 |
8.5741 |
|
12-1/2x12-1/2 |
6.9223 |
7.7190 |
8.3022 |
8.7221 |
|
12-1/2x14 |
8.1096 |
8.814 |
9.2242 |
9.5620 |
|
13x13 |
7.9808 |
8.899 |
9.5721 |
10.0553 |
|
13x14 |
8.8448 |
9.6899 |
10.2923 |
10.7146 |
|
13-1/2x14 |
9.6079 |
10.6134 |
11.4705 |
11.8553 |
|
14x14 |
10.4569 |
11.6590 |
12.5423 |
13.1752 |
|
14-1/2x14-1/2 |
11.9875 |
13.3671 |
14.3781 |
15.1034 |
|
15x15 |
13.8927 |
15.4942 |
16.6666 |
17.5070 |
|
15-1/2x15-1/2 |
15.3491 |
17.1144 |
18.4060 |
19.3386 |
Specification List of PVC Coated Barbed Wire:
|
Core Wire Diameter |
Outside Diameter |
|
1.0mm-3.5mm BWG.11-20 SWG. 11-20 |
1.4mm-4.0mm BWG. 8-17 SWG. 8-17 |
|
Note: Thickness of P.V.C. coating layer: 0.4mm-0.6mm | |
Razor Barbed Wire
Barbed wire are wire products of great versatility, as they allow to be installed over wire fences for small farms and sites. Barbed wire is a product recommended for the construction of strong and lasting fencings. It is extremely adapted to control heavy and wild animals.
We offer barbed wire of different patterns including razor type, one of the most popular kinds to strengthen fencings.
|
Razor Barbed Wire Specification | ||||
|
Outside Diameter |
No. of Loops |
Standard Length per Coil |
Type |
Notes |
|
450mm |
33 |
8M |
CBT-65 |
Single coil |
|
500mm |
41 |
10M |
CBT-65 |
Single coil |
|
700mm |
41 |
10M |
CBT-65 |
Single coil |
|
960mm |
53 |
13M |
CBT-65 |
Single coil |
|
450mm |
112 |
17m |
BTO-12.15.20.22 |
Cross type |
|
500mm |
102 |
16M |
BTO-12.15.20.22 |
Cross type |
|
600mm |
86 |
14M |
BTO-12.15.20.22 |
Cross type |
|
700mm |
72 |
12M |
BTO-12.15.20.22 |
Cross type |
|
800mm |
64 |
10M |
BTO-12.15.20.22 |
Cross type |
|
960mm |
52 |
9M |
BTO-12.15.20.22 |
Cross type |
Razor Wire Security Fencing
Razor barbed wire fencing and razor wire concertina makes the majority of our products. Razor barbed wire fencing is usually made of galvanized steel blade or stainless steel blade. Two pieces of stainless steel razor wire or zinc-coated razor wire can be bounded together by clips to make it stronger. The spiral intersecting barbed wire presents an intersecting shape after opening with beautiful outlook and practical property.
