Chongqing Tansing Machinery Co.,Ltd
China Manufacturer with main products: Air Compressor, Bungee, Diesel Generator, Marine Boiler |
SC-WS001 Air Compressor
| FOB Price: | 50.00 - 5000.00 USD/Set |
|---|---|
| Shipping: | 15days |
| Payment Terms: | T/T(Bank Transfer), Western Union |
| Place of Origin: | Shanghai in China |
|---|---|
| Packaging Details: | Standard |
Specifications
|
Water Cooled Screw Air Compressor | ||||||
| Product No. | SC-WS001 | |||||
| Displacement temperture | water-cooling | |||||
| Ambient temperture+45 | ||||||
| Free air deliver (M3/min) | 43.0/41.0/37.8/34.6 | |||||
| Discharge pressure(Mpa) | 0.7/0.8/1.0/1.2 | |||||
| Dimension(LXWXH)( mm) | 3200X2100X2100 | |||||
| Drive method | Direct drive | |||||
| Starting method | Y-Starter | |||||
| Cooling Model | water cooling | |||||
| No of compression stage | Single Stage | |||||
| Electricity (V/ph/Hz) | 380/3/50 | |||||
| Ambient temperture(oC) | -5~+45 | |||||
| Noisc level (db(A)) | 75±2 | |||||
| Motor Power (kw) | 250 | |||||
| Lubricant ( L) | 100 | |||||
| Weight ( kg) | 5000 | |||||
| Air Outlet Pipe Diameter(NPT)(inch) | G2" | |||||
| water cooled screw air compressor features as follows: | ||||||
| 1. Quite operation means you can comfortably work while it is running all day long. | ||||||
| 2. The lowest specific power consumption save your operating expense every day. | ||||||
| 3. Easy access to all service items means you will spend less time taking care of the machine. | ||||||
| The screw air compressor main configures as follows: | ||||||
| 1. Main frame: Sweden Atlas | ||||||
| 2. Bearing:100% Sweden SKF (LIFE60000hours ) | ||||||
| 3. Solenoid valve: CEME Italy | ||||||
| 4. Electro motor: ABB WOLONG | ||||||
| 5. Thermostat valve : Austria Hoerbiger | ||||||
| 6. Pressure sensor: Switzerland Huba imported with original | ||||||
| 7. Container: shanghai shenjiang | ||||||
| 8. Oil filter: Germany MANN company imported with original | ||||||
| 9. Oil and gas separator: Germany MANN company imported with original | ||||||
| 10. Lubricating Oil: Sweden Atlas screw air compressor oil imported with original | ||||||
| 11. Suction valve: Sweden Atlas imported with original | ||||||
| 12. Pressure valve: Hoerbiger Austria company | ||||||
| 13. PLC: Schneider Electric France | ||||||
| 14. Oil system configuration of the pipeline were chrome-plated brass | ||||||
