Nozzles/filter Strainers

Haixing Nozzles, manufactured uniquely in stainless steel or alloy, are successfully used in mixed beds, ion exchangers and regenerators of condensate polishing system.
The wedge wire element in a nozzle is a screen pipe. Nozzles are closed on one side and have a threaded fitting on the other. There are one rubber shim, one steel shim and two thin nuts of the same material for a nozzle. Material: SUS304, 1Cr18Ni9Ti, AISI316L, 316 and Haynes alloy C etc.
Nozzles can be used for liquid/solid or gas/solid separation, or media retention (sand, catalyst, resin,).The nozzles are mounted on a support plate. The dimensions and the distribution of the nozzles on the support plate can be altered to obtain an optimized flow distribution.
Above mentioned designs are used widely in down-flow reactors for liquid/solid or gas/solid separation. The liquid or gas can flow through the nozzles while the solids are retained in the vessel by the nozzles.
high strength compared to plastic nozzles
flexibility in design
strong construction (self supporting)
large open area
plug-resistant slot design
We can also make manufacture according to your detail specifications and we assure that we will give you the best services.
If you are interested in our products please feel free to contact us and your inquiry will meet with our careful attention. Haixing Sandra Xu will serve you with best quality products.
