CNC router Laser Engraver machine/PROFILE LAMINATOR/Auto Cutting Machine

FOB Price:	100000.00 USD/Metric Ton
Supply Ability:	200,000 Metric Ton per Year
Shipping:	PROMPT
Payment Terms:	L/C, T/T(Bank Transfer)

In Stock

Inquiry Now

Product Details

Place of Origin:	Shandong in China
Packaging Details:	AS YR REQUIREMENT

Specifications

K45MT-3 Series

Technical Parameter:

Model	K45MT-3
Machine size	1,300 x 3,100mm
Work envelope	1,300 x 2,500mm
Resolutions	0.0025mm
Y movement	Rack and pinion, gear drive/Taiwan
X, Z movement	Ball screw drive/Germany
Guide	Linear ￠20 square/Taiwan
Max. speed	20m/min
Max. cutting speed	10m/min
Spindle power	4.5 kw/set
Spindle speed	18,000rpm/min
Bridge clearance	200 mm
Working voltage	AC380V/50Hz
Command code	HPGL,G code

K2030 Series

Technical Parameter:

Model	K2030
X-Y-Z axis working area	2,000 x 3,000 x 200mm
Machine size	2,800 x 3,710mm
Resolutions	0.025mm
X-Y movement	rack and pinion, gear drive/Taiwan
Z movement	ball screw drive/Germany
Guide	Linear ￠20 square/Taiwan
Max. speed	35,000mm/min
Max. cutting speed	25,000mm/min
Spindle power	4.5kw(water cooling) /Japan NSK
Spindle speed	24,000rpm
Inverter power	7.5kw
Drive motors	stepper
Working voltage	AC380V/50-60Hz, 3-phase
Command code	G code
Computer interface	USB 2.2
Collet	ER25-12.7mm,6mm,3.175mm
Software	Type3 Software/France
Controls	DSP0501 (Digital Signal Processor)
Packing dimensions	2300 x 3810 x 1960 mm,2500 kgs
Equipment available	a.Vacuum hold down b.Auto cut adjusting device c.Oil lubrication system d.Clamps and vacuum fitting

Laser Engraver K400L
Technical Parameter:
Working Size: 400mm*400mm
Laser Power: 40W
Laser Tube: Co2 sealed glass laser tube
Engraving Speed: 1-60000mm/min
Cutting Speed: 1-10000mm/min
Cooling system: water-cooling and protection system
Location precision: <0.01mm
Resolution ratio: 0.025mm
Minimum shaping character: Letters 1 x 1mm
Support Format: BMP, PLT
Operating temperature: 5-40°C Operating humidity: 5%-95% free of condensed water
Applicable materials: Non-metal materials such as double color board, plexiglass, glass, bamboo and wood, rubber, marble, granite and tiles, leather

CNC ROUTERS K1530
(Working Area 1520mm X 3050mm, German Ball Screw, Taiwan Linear Rail, DSP 0501 System, 4.5kw Water Cooling Spindle.)

Technical Parameter:

Model	K1530
X-Y-Z axis working area	1,500 x3,000 x 200mm
Machine size	2,300 x 3,650mm
Resolutions	0.025mm
X-Y movement	rack and pinion, gear drive/Taiwan
Z movement	ball screw drive/Germany
Guide	Linear ￠20 square/Taiwan
Max. speed	35,000mm/min
Max. cutting speed	25,000mm/min
Spindle power	4.5kw(water cooling) /Japan NSK
Spindle speed	24,000rpm
Inverter power	7.5kw
Drive motors	stepper
Working voltage	AC380V/50-60Hz, 3-phase
Command code	G code
Computer interface	USB 2.2
Collet	ER25-12.7mm,6mm,3.175mm
Software	Type3 Software/France
Controls	DSP0501 (Digital Signal Processor)
Packing dimensions	2300 x 3670 x 1960 mm,2000 kgs
Equipment available	a.Vacuum hold down b.Auto cut adjusting device c.Oil lubrication system d.Clamps and vacuum fitting

PROFILE LAMINATOR

Product	Model NO
Profile laminator	FM-300
Profile Laminator	FM-1100

The machine is used for surface colorful lamination of PVC plastic, alu-alloy or reinforced glass doorwindow profile. It uses melt glue and auto-matical friction glue system. The glue box includes bulk melter. This machine can automatically remove dust, preheating, coat af-finity agent, automatically friction coat protective film. Using speed ad-justment system, man-machine device is run by

English.

Profile Laminator FM-300

Technical parameter

1) Total power:17KW

2) Power supply:380V 50Hz

3) Electric heating:13KW

4) Transmission power:4kw

5) Laminating width:20-300mm

6) Laminating height: 125mm

7) Laminating speed:0-30m/min

8) Overall dimention:4000*700*2300(mm)

9) Weight:3600Kg
