Gui Lin Jinda Mechanical Equipment Factory
China Manufacturer with main products: Bi-Metal Contact Machine, Metal Contact Machine, Silver Rivert Machine, Silver Contact Machine, Double Metal Contact Machine, Double Metal... |
Home
>Products Catalog > Bi-Metal Contact Machine / Double Metal Combined Machine / Metal Contact Machine / Welding Machine
Bi-Metal Contact Machine / Double Metal Combined Machine / Metal Contact Machine / Welding Machine
| FOB Price: | 100.00 - 10000.00 USD/Set |
|---|---|
| Supply Ability: | 500 Set/Sets per Year |
| Shipping: | 15 days |
| Payment Terms: | T/T(Bank Transfer) |
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
Related products from verified members
| Place of Origin: | Guangxi in China |
|---|---|
| Packaging Details: | wood case |
Specifications
Mold: JD-YFC16
Name: bi-metal contact machine / double metal combined machine / metal contact machine / welding machine
Main Parameter and feature:
Dia of the rivet head:2.0-6.0 mm
Thickness of the rivet head:2.2mm-Max
Dia of the rivet shank:1.0-3.5mm
Length of the rivet shank: :Min-0.2 mm/6mm-Max
Production rate:6000-10000 pcs/H (stepless speed regulation)
Driving power of the main motor: 3 kW
Consumed power of the whole machine: 4 KW
Power Supply: 380 v, 50 HZ
Easy to operate, save sliver and power.
Usage:
to make Ag/Cu,AgNi/Cu,AgCd0/Cu double metal contact, which widely used in circuit breaker, timer, starter, relays, contactors, switches etc
The only authorized manufacturer by Guilin Appliance scientific Research Institute of China Mechanical Group of Bi-metal contact machine.
Mold: JD-BCM16
Name: bi-metal contact machine / double metal combined machine / metal contact machine / welding machine
Main Parameter and feature:
Dia of the rivet head:4.0-9.0 mm
Thickness of the rivet head:3.0mm-Max
Dia of the rivet shank:Min-0.2 mm/8mm-Max
Production rate:3000-10000 pcs/H (stepless speed regulation)
Driving power of the main motor: 7.5kW
Consumed power of the whole machine: 8.5 KW
Power Supply: 380 v ± 10%, 50 HZ,
Usage:
to make Ag/Cu,AgNi/Cu,AgCd0/Cu double metal contact, which widely used in circuit breaker, timer, starter, relays, contactors, switches etc
