Product Details

Place of Origin:	Guangdong in China
Packaging Details:	standard export packing

Specifications

The ALPHA Series incluce ALPHA S2,ALPHA M3,ALPHA B-15.They are suitable for large scale perforance,gymnasium ,theater and other large venue sound reinforcement.
Technical specification:
Model: ALPHA M3
Effective frequency response: 190Hz-19KHz 3dB
MF combination: 1* 10"
HF combination: 1* 3"
MF/HF power: 500-1000W/150-300W
MF/HF sensitivity: 110/120dB
MF/HF max SPL: 135/142dB
Coverage angle: 35*35
Strusture: High definition plank
Finish: Ash white Ordet the paint
Connector: SPEAKON*3
Grille: Perforated metal
Net weight: 22Kg
Shipping size: 711*439*394mm

ALPHA B-15
Technical specification:
Model: ALPHA B-15
Effective frequency response: 42Hz-180KHz 3dB
LF combination: 1* 15"
LF/MF power: 500-1000W
LF/MF sensitivity: 106dB
LF/MF max SPL: 140dB
Coverage angle: 35*35
Strusture: High definition plank
Finish: Ash white Ordet the paint
Connector: SPEAKON*3
Grille: Perforated metal
Net weight: 22Kg
Shipping size: 711*439*394mm

ALPHA S2
Technical specification:
Model: ALPHA S2
Effective frequency response: 29Hz-19KHz 3dB
LF combination: 2* 18"
LF/MF/HF power: 1200-2400W
LF/MF/HF sensitivity: 105dB
LF/MF/HF max SPL: 140dB
Strusture: High definition plank
Finish: Ash white Ordet the paint
Connector: SPEAKON*3
Grille: Perforated metal
Net weight: 29Kg
Shipping size: 1200*689*754mm

WSX-18B
Model: WSX-18B
LF driver: 1* 18" SUB
Frequency response(Hz): 36Hz-250Hz
Sensitivity(SPL 1W@1M): 99dB
RMS power RMS(W): 600
Peak power(W): 1200
Impedance(ohms): 8
Structure: Wooden board
Finish: Ash white Ordet the paint
Connector: SPEAKON*2
Grille: Perforated metal
Shipping size: 572*1066*936
