glass straight-line double edging machine

Inquiry Now

Glass Cutting Machine with Automatic Loading

Price:8,600.00-10,600.00 USD/Set

Min. Order:1 Set
Double Bending Glass Tempering Furnace for Car ...

Price:300,000.00-500,000.00 USD/Set

Min. Order:1 Set
LM-9060 glass engraving machine

Price:3,000.00-5,000.00 USD/Set

Min. Order:1 Set
Glasswool Production Line

Price:

Min. Order:
Jinan besr Glass Engraving Machine

Price:6,000.00-7,500.00 USD/Set

Min. Order:1 Set
Fused Cast AZS for Glass Furnace

Price:2,000.00-6,000.00 USD/Metric Ton

Min. Order:1 Metric Ton
Spacers for Double Conductor

Price:1.00-20.00 USD/NING BO

Min. Order:
3D Crystal Laser Inner Machine (STNDP-801AB4)

Price:

Min. Order:

Place of Origin:	Guangdong in China
Packaging Details:	Film Package

Specifications

1.Brief Introduction:

1.1 The double parallel straight lines' bottom and arrises of glass can be processed at one time by rough,fine grinding and pneumatic polishing.

1.2 Installed with excellent linear guide and screw mandrels which ensure the processing precision.

1.3 The main drive adopts inverter and the whole machine is controlled by PLC.

2.Technical Parameter:

A Max.processing size:1500mm

B Min.processing size:150*150mm

C Processing thickness:3-19mm

D Processing speed:0.5-7m/min

E Weight:3500kg

F Power:21.7kw

G Size of the whole machine:3270*3240*1900mm
