Beijing Kinglong New Enerjy Technology Co., Ltd.
China Manufacturer with main products: Solar Inverter, PV Inverter, Solar Converter, Grid-Tied Solar Inverter |
solar inverter Sunteams 4000
| FOB Price: | 700.00 - 2,000.00 USD/Set |
|---|---|
| Supply Ability: | 15,000 Set/Sets per Month |
| Shipping: | 40 days after receive your payment in advance |
| Payment Terms: | L/C, T/T(Bank Transfer) |
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
| Place of Origin: | Beijing in China |
|---|---|
| Packaging Details: | Carton |
Specifications
Features
1.The maximum efficiency of the inverter can reach 98.00%
2.MPPT efficiency >99.5%
3.Non-fan design
4.KLNE products have already acquired many international certifications including CE, TUV, VDE (Germany) and AS4777 / AS3100 for the Australian market.
5.Internal GFCI device
6.Built-in leakage current protection device
7.IP65 protection
8.Transformer-less design
9.Optional DC switch
10.RS232 & RS485 communication
11.Meets RoHS
12.Designed for hanging with simple and easy installation
Specifications
|
Specifications
|
Sunteams 4000
|
|
Input data
|
|
|
Max.DC power
|
4540W
|
|
Max.DC voltage
|
550V
|
|
System start-up voltage
|
150V
|
|
PV voltage range MPPT
|
250V-530V
|
|
Max.input current
|
19A
|
|
DC voltage ripple
|
< 5%
|
|
Number of MPP trackers
|
1
|
|
Max.number of strings
|
4
|
|
Output data
|
|
|
Nominal AC output
|
4000W
|
|
Max.AC power
|
4400W
|
|
Max.output current
|
20A
|
|
THD of AC current
|
< 3%
|
|
Grid voltage range
|
220V-240V
|
|
Grid frequency range
|
50Hz/60Hz
|
|
power factor(cos φ)
|
1
|
|
Number of feed-in phases
|
single-phase
|
|
Efficiency
|
|
|
Max.efficiency
|
98.00%
|
|
Euro ETA
|
97.50%
|
|
Device protection
|
|
|
Reverse polarity protection
|
short-circuit diode
|
|
DC switch
|
optional
|
|
Short-circuit proof
|
Yes
|
|
Ground fault monitoring
|
Yes
|
|
Grid monitoring
|
Yes
|
|
Ground fault current detection
|
optional
|
|
General data
|
|
|
Dimensions(height x width x depth)
|
457/368/195
|
|
Weight
|
20kg
|
|
Ambient temperature
|
-25 C° to +60 C°
|
|
Noise development
|
<30 dB(A)
|
|
Power Consumption
|
Night - 0W
|
|
Topological structure
|
transformerless
|
|
Cooling
|
free convection
|
|
IP degree of protection
|
IP65
|
|
Feature
|
|
|
DC connections
|
MC4
|
|
AC connections
|
plug connector
|
|
Display
|
LCD/LED
|
|
Accessory interfaces
|
RS485/RS232
|
|
Standard warranty
|
5 years
|
|
Certificates
|
CE/VDE/TUV/AS
|
