rp902 PAVER

Shipping:	25
Payment Terms:	L/C, T/T(Bank Transfer)

Inquiry Now

Related products from verified members

Product Details

Place of Origin:	Jiangsu in China

Specifications

RP902 Multi-function paver is a construction machine mainly used for the paving project on the road base and surface for highway of various kinds of material. This type of machine has the most advanced technology, such as computer-controlling system, ultra sonic sensor, electric auto-leveling system, faults self-diagnosis, hydraulic extension screed, dual-tamper and eccentric vibration, which makes the complete machine work stably at speed, uniformly material flow, high pre-compaction, good smoothness, easy and convenient operation, all the key parts are purchased from international manufacturers to ensure the complete machine with the same quality and reliability as that of imported machine. therefore, RP902 paver becomes the ideal equipment for the paving job on stabilized soil for road base and asphalt concrete for road surface.

Main Features:

● Driving system with dual control for the right and the left tracks separately and the automatic-computer-control technology ensure the paving speed constantly.

● Adopted with an advanced, mature, reliable and powerful DEUTZ BF6M1013E diesel engine.

● The fixed Three –in-one hyper-power thermal exchanger discharges the heat compulsively and concentratively, so the paver can operate continuously under the condition of 50℃ for a long time.

● Four sets of separste full hydraulic transmission are adopted in the conveyor auger system both on the right and left sides; and the ultra sonic sensor technology controls material level constantly.

● Material augers can move up and down expediently, so as to adapt different paving thickness and reduce material segregation.

● The electric auto-leveling technology ensures the qualified smoothness.

● The technologies of dual tamper bars, eccentric vibrators and electric-heating system are adopted in the hydraulic extension screed to gain the highest pre-compacted density.

● Conveyor bottom plates, distributing augers, and screed bottom plates are made of high wearing-resistant alloy and imported wearing-resistant material to prolong the service life.

● Control panel shows directly and clearly all working parameter, and could be mounted either on right or left side.

● The mobile auto-leveling reference beam and contactless ultra sonic sensors could be available as an option.

MAIN TECHNICAL SPECIFICATIONS

Item	unit	parameter
Basic working width	m	3.0
Max. working width	m	9.0
Max. paving thickness	mm	350
Paving speed	M/min	0-18
Traveling speed	Km/h	0-2.2
Theoretical productivity	T/h	700
Hopper capacity	T	14
Gradient ability	%	20
Smoothness	mm/3m	3
Slope leveling tolerance	%	±0.02
Engine type		BF6M1013E
Rated output	KW	137
Rated rev	rpm	2300
Tank Capacity	L	270
Generator Power	KW	33
Weight	t	23-28.6
Overall dimension	mm	7150×3000×3850

Structure and specification are subject to change without notice
