Shenzhen B&D Creative Co., Ltd.
China Manufacturer with main products: IP Cameras, CCTV Cameras, DVR, DVS |
IP Dome Camera (BD-639Q-B0L7)
| Supply Ability: | 100,000 Piece/Pieces per Week |
|---|---|
| Shipping: | Quickly Delivery |
| Payment Terms: | L/C, T/T(Bank Transfer) |
Related products from verified members
| Place of Origin: | Guangdong in China |
|---|---|
| Packaging Details: | Gift Box |
Specifications
| CPU | Operation system | Embedded Linux OS |
| Video | Compression format | MPEG-4 |
| Signal system | PAL or NTSC | |
| Frame ratio | PAL: 25fps,NTSC:30fps | |
| Resolution | PAL：D1(720*576), CIF(352*288), FIELD(720*288), QCIF(176*144) | |
| Picture adjust | Brightness, contrast, chroma, saturation adjustable | |
| sensor | 1/4〞 LG CCTV all in one camera | |
| Horizontal Resolution | 480 line | |
| Optical Zoom | 27 times Optical Zoom f= 3.2mm-86.4mm | |
| Minimum illumination | 0.1 Lux/F1.6 | |
| S/N ratio | 48dB ">>48dB | |
| Electric shutter | PAL：1/50s-1/100,000s NTSC：1/60s -1/100,000s | |
| White balance, backlight balance | Auto | |
| Focus | Manual/auto | |
| Video output | Accept external connection video output BNC interface 1.0Vp-p/75Ω | |
| Audio | Processor | One way Audio（ Accept MIC） RCA interface |
| Audio Gain | （AGC） | |
| Network | Network interface | RJ-45 10/100Mb self-adaptable Ethernet slot |
| Delay time | < 500 MSEL(0.50 second) in lan | |
| RTSP | Support RTSP 3G cell phone monitor( support Nokia Sybiam S60 System, Windows mobile system） | |
| Network procotol | TCP/IP,HTTP,ICMP,DHCP,FTP,SMTP,PPPoE etc. | |
| Simultanious visitor | Support 15 direct visitors at the same time，but no limitation when using forwarder Server. | |
| IP mold | Dynamic IP address,Static IP address,PPPOE | |
| P/T |
Control | Built-in RS485 P/T control Level 360° , Vertical 90° ，zoom |
| Revolution angle | Level：0°～ 360°，Vertical：0°～ 90° | |
| Revolution speed | Level：200°/s ; Vertical: 200°/s | |
| Rotation limitation | 128 preset positions，Auto Cruise,support preset position zoom | |
| Other | Material | Dome cover ：PMMA optional material Doom body:plastic |
| Use environment | Outdoor use | |
| Waterproof range | Ip66 | |
| Power | DC15V 2.4A | |
| Operating Temperature | -10~50 °C | |
| Operating Damp | 95% RH | |
| Size | Item size: 222mm x275mm (D xH） Packaging size: 460mm x 300mm x 310mm (LxWxH) | |
| Weight | Net：4200g Gross：5800g (Note: All products as per the material subjects） | |
| Attachment | Adaptor, Disc（including introduction）, Manual, bracket | |
| Alarm | input/output | 1/1 |
| Alarm detector | Motion detection setting | |
| Intelligent Motion detection | support 16 Regional Motion Detection | |
| Alarm action | support Email photo,FTP photo,FTP video,message,etc.alarm | |
| System | System deployment | Microsoft Win98 SE/ME/2000/XP,Vista, Internet Explorer 5.0, NET4.5 or above |
| Features | Security Settings | Supports two-level password: administrator authority, user authority |
| DDNS（free） | Free DDNS bounded i.e., http://demo.easynp.cn. | |
| Superiority | p2p technology, mobile view | |
| Center management software（free) | 1,4,9,16,25,36 or 64 multiple video display optional in one screen, support record, alarm, remote playback on records and other management functions. | |
| Certification | certification | ISO CCC FCC CE |
