Metal Hydride Hydrogen Storage Device

FOB Price:	258.00 - 958.00 USD/Unit
Supply Ability:	5,000 Unit/Units per Month
Shipping:	10 days after confirming the payment
Payment Terms:	L/C, T/T, Western Union

In Stock

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Product Details

Export Markets:	North America, Eastern Europe, Southeast Asia, Africa, Mid East
Place of Origin:	Beijing in China
Packaging Details:	box or other standard export packing

Quick Details

Brand Name: Whole Win

Specifications

Metal Hydride Hydrogen Storage Device

Introduction: The devices can be used as purifying devices in which the purified hydrogen is released and impurity-include hydrogen gas is purified again. The devices also can be multi-functionally used as purifying, storing and transporting devices in which the purified hydrogen is continuously stored, or stored and transported

1.Small Size

Model	HYM-30S	HYM-50S	HYM-100S/A	HYM-300S	HYM-500S	HYM-750S/A	HYM-1000S
Capability of hydrogen storage	≥30 Liter	≥50Liter	≥100 Liter	≥300 Liter	≥500 Liter	≥750 Liter	≥1000 Liter
Measurement for reference (mm)	DIA40×L90	DIA 40×L130	DIA 46×L210/ DIA 57×L200	DIA 66×L310	DIA 78×L360	DIA 87×L450/ DIA 107×L430	DIA 100×L460
Gross Weight (kg)	≤0.9	≤1.2	≤2.5	≤5	≤8	≤15	≤17
Material of Pot	steel	steel	steel /aluminum alloys	steel	steel	steel /aluminum alloys	steel
Pressure of hydrogen storage	≤3 MPa	≤3 MPa	≤3 MPa	≤3 MPa	≤3 MPa	≤3 MPa	≤3 MPa
Time of hydrogen charging(25°C)	≤30 min	≤50 min	≤60 min	≤70 min	≤90 min	≤150 min	≤160 min
Released speed of hydrogen (25°C)	≥1 L/min	≥1 L/min	≥1 L/min	≥2 L/min	≥3 L/min	≥4 L/min	≥4L/min

2.Large Size

Model	HYM-5M	HYM-10M	HYM-30M	HYM-40M	HYM-50M	HYM-80M
Capability of hydrogen storage	≥5 m3	≥10 m3	≥30 m3	≥40 m3	≥50 m3	≥80 m3
Measurement for reference (mm)	DIA 300×L800	DIA 410×L900	DIA 520×L1520	DIA 600×L1500	DIA 630×L1680	DIA 550×L2100
Gross Weight (kg)	≤120	≤230	≤600	≤800	≤950	≤1000
Material of Pot	steel	steel	steel	steel	steel	steel
Pressure of hydrogen storage	≤3 MPa	≤3 MPa	≤3 MPa	≤3MPa	≤3 MPa	≤3 MPa
Time of hydrogen charging (25°C)	≤60min	≤60min	≤120min	≤120min	≤150min	≤150 min
Released speed of hydrogen (25°C)	≥20 L/min	≥35 L/min	≥60 L/min	≥80 L/min	≥90 L/min	≥200 L/min
