Formed Steel Pipe Linking & Straightening Machine

Supply Ability:	100 Set/Sets per Year
Shipping:	20-40 days
Payment Terms:	L/C, T/T(Bank Transfer)

Inquiry Now

Product Details

Place of Origin:	Shandong in China
Packaging Details:	for shipment

Specifications

Applicable industry:
Mainly used for coiling or bending and pressing & linking of formed steelpipe so as to weld steelpipe easily, also used for linking & welding of round pipe, taper pipe and prism pipe. The machine has wide application in the below industry, such as petrochemical, electric power, shipbuilding and chemical industry, etc.

Product feature:

1.The machine installs main-cylinder on the upper, individually equips one clamping cylinder on the two sides, clamping cylinder may go up & down which can realize linking of various steelpipe with diameter between 500mm ~ 1500mm by using lengthened bar.

2.The machine with V-type worktable on the underside.

3.Install electric driving roller on the front & rear to decrease the working intension of workers.

4.The machine may install front &rear to straighten steelpipe,one machine with two fuctions.

Product Basic Parameter:

Model	THF150
Functions	Coiling or bending, and linking & straightening for formed steelpipe
Pressure of upper cylinder(kN)	1000/2500 (Used for alignment)
Stroke of upper cylinder(mm)	500
Pressure of side cylinder(kN)	250
Stroke of side cylinder(mm)	450
Scope of steelpipe(mm)	Φ500~Φ1500
Up & down position of side cylinder	Auto adjustment
Adjustable stroke(mm)	600
Adjustable way of steelpipe(mm)	Manual or mechanical
Total power of motor(kW)	11/18.5
Overall dimensions L×W×H(m)	28×6×6
The machine-frame with closed structure
