Air Conditioner Motor Capacitor

FOB Price:	5.00 USD/Piece
Shipping:	25 days
Payment Terms:	T/T

In Stock

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Related products from verified members

WS

Price:

Min. Order:
5.5V 0.47F Super Capacitor

Price:

Min. Order:
Aluminum Bottle Screw Cap

Price:0.05-0.06 USD/Piece

Min. Order:100,000 Pieces
high voltage small super capacitor bank 5.5v 5v...

Price:0.10-0.80 USD/Piece

Min. Order:100 Pieces

Product Details

Place of Origin:	Zhejiang in China
Packaging Details:	export carton

Specifications

Place of Origin	Zhejiang, China (Mainland)
Model Number	CBB61
Approve	passed CE,CQC and UL
Motor Capacitor Type	polypropylene film capacitor
Application	A/C motor

Main uses:

Applied 50/60Hz AC motor for starting and running, such as airconditioner fan, electric fan, ventilator fan, booster fan etc.

Products character:

Cuboid flame-retardant plastic case, with tap or line outleads, fully filled with epoxy resin.
Good self-healing, small size, low loss, stable capacitance, long life, reliable performance etc.

Technique Data:

Standard GB3667.1-2005, IEC60252-1:2001, UL810
Capacitance range 1μF to 24μF
Capacitance deviation ±5% or according to customers’ requests
Rated Voltage 250VAC, 450VAC, 500VAC
Rated frequency 50/60Hz
Operating Temperature -40 to +70
Class of safety protection P0
Testing voltage T-T:2.0Un/60S
Tangent of loss angle tanσ≤0.002 (100Hz)
Size Refer to our design
Above is our normal specification, we are able to design and produce according to customers’ special requirements.

SPECIFICATIONS:

CBB61 sizes

Voltage(VAC)

370VAC

440VAC

cap.(μF)

Size(mm)

A*B*H

32*14*25

1.2

32*14*25

1.5

38*14*26

2.5

38*18*30

3.5

38*18*30

48*18*34

47*26*38

62.5*28*45

Remark: A: Case Length ; B-Case Width; H- Case Height

Remarks: The specifications can be according to cilents requests
