Jiangsu Sanxing Machinery Manufacture Co., Ltd.
China Manufacturer with main products: Wire Cut Edm, Die Sinking EDM, Hole Drilling Machine, CNC Engraving Machine, CNC Milling Machine, CNC Machine Center, Wire Edm, Wire Cut |
| Place of Origin: | Jiangsu in China |
|---|
Specifications
|
TYPE |
UNIT |
7135 |
714(650) |
715(850) |
716(1060) |
717A (1270) |
717B(1370) |
718(1580) |
719B(1890) |
|
Three axises travel |
mm |
550 |
650 |
800 |
1000 |
1200 |
1300 |
1500 |
1800 |
|
X-axis travel |
mm |
350 |
400 |
500 |
600 |
700 |
700 |
800 |
900 |
|
Y-axis travel |
mm |
380 |
480 |
500 |
600 |
650 |
700 |
700 |
680 |
|
Z-axis travel |
mm |
100-150 |
80-560 |
105-650 |
170-770 |
150-750 |
150-800 |
170-870 |
160-840 |
|
Travel between spindle nose to worktable |
mm |
360 |
480 |
550 |
600 |
785 |
785 |
800 |
950 |
|
Travel between spindle center to worktable |
mm |
360 |
480 |
550 |
600 |
785 |
785 |
800 |
950 |
|
work table |
|
|
|
|
|
|
|
|
|
|
Length of work table |
mm |
800 × 320 |
800 × 420 |
950 × 460 |
1360 × 600 |
1360 × 700 |
1400 × 710 |
1700 × 800 |
2000 × 900 |
|
max. loading capacity of worktable |
kg |
300 |
600 |
600 |
1000 |
1000 |
1000 |
1500 |
1600 |
|
table-T solt |
mm |
3-14 |
5-18 |
5-18 |
5-18 |
5-18 |
5-18 |
5-22 |
5-22 |
|
Spindle |
|
|
|
|
|
|
|
|
|
|
Spindle taper |
|
BT30 |
BT40 |
BT40 |
BT40 |
BT50 |
BT50 |
BT50 |
BT50 |
|
Spindle speeds |
r/min |
60-8000 |
60-8000 |
60-8000 |
60-6000 |
60-6000 |
60-6000 |
60-6000 |
60-6000 |
|
Power of motor(spindle) |
kw |
3.7 |
5.5/7.5 |
5.5/7.5 |
7.5/11 |
11/15 |
11/15 |
15/18.5 |
18.5/21 |
|
motor of motor(three avises) |
kw |
1.5 |
1.5 |
1.5 |
2 |
3.5 |
3.5 |
3.5 |
4.5 |
|
Feed |
|
|
|
|
|
|
|
|
|
|
Max.moving speed of X |
m/min |
16 |
16 |
16 |
16 |
16 |
16 |
16 |
16 |
|
Max.moving speed of Y |
m/min |
16 |
16 |
16 |
16 |
16 |
16 |
16 |
16 |
|
Max.moving speed of Z |
m/min |
12 |
12 |
12 |
12 |
12 |
12 |
12 |
12 |
|
style of handle |
|
BT30 |
BT40 |
BT40 |
BT40 |
BT50 |
BT50 |
BT50 |
BT50 |
|
CNC system |
|
|
|
|
|
|
|
|
|
|
CNC system |
FANUC 0i MC |
|
|
|
|
|
|
|
|
|
Accuracy |
|
|
|
|
|
|
|
|
|
|
Position accuracy |
mm |
0.01/500 |
0.01/500 |
0.01/500 |
0.01/500 |
0.016/500 |
0.016/500 |
0.016/500 |
0.016/500 |
|
Repeatability position accuracy |
mm |
0.005 |
0.005 |
0.005 |
0.005 |
0.006 |
0.006 |
0.006 |
0.006 |
|
Net weight |
kg |
3200 |
4000 |
5000 |
8000 |
8500 |
10000 |
13500 |
18000 |
|
Pressure requirement |
kg/cm 2 |
6 |
6 |
6 |
6 |
6 |
6 |
6 |
6 |
|
Power supply |
kw |
10 |
12 |
15 |
20 |
25 |
25 |
32 |
36 |
|
Machine dimensions(L × W × H) |
mm |
2200 × 1600 × 2000 |
2400 × 2000 × 2500 |
2600 × 2200 × 2800 |
3120 × 2290 × 3000 |
3600 × 2700 × 3100 |
3800 × 2800 × 3200 |
4200 × 3100 × 3200 |
4600 × 3400 × 3500 |
