Specifications
|
Specifications |
|
|
Rated line pull: |
16500 Lbs (7491kgs) single line. |
|
Motor Desplacement: |
80ml/r |
|
Gear Train: |
4 stage gear-driven |
|
Gear ratio: |
50 : 1 |
|
Max.Flow: |
60L/min |
|
Max.Pressure: |
14Mpa |
|
Clutch: |
Sliding Ring gear |
|
Braking action: |
Automatic in the ratchet whell |
|
Fairlead: |
4-way Roller fairlead |
|
Wire rope: |
15/32"×92'( 12mm ×28m) |
|
Drum size: |
3.46"×8.82"( 88mm×224mm) |
|
Dimensions: |
600mm×215mm×252mm) |
|
Bolt pattern: |
10"×4.5"(254mm×114.3mm)/10"×6.3"(254mm×160.1mm) |
|
N.W: |
70 kg (154Lbs) |
|
Line pull and pressure difference |
||||||
|
Single line pull |
Lbs |
0 |
4000 |
8000 |
12000 |
16500 |
|
Kgs |
0 |
1816 |
3632 |
5448 |
7491 |
|
|
Pressure difference between motor entry and exit |
Map |
1.0 |
3.0 |
6.0 |
9.0 |
12 |
|
Line pull and cable capacity |
|||||
|
Layer of cable |
1 |
2 |
3 |
4 |
|
|
5Line pull |
Lbs/kgs |
16500 |
13306 |
11148 |
9593 |
|
Line speed |
FPM/mpm |
11.5/3.5 |
14.8/4.5 |
18/5.5 |
21.3/6.5 |
|
Flow |
G/min/L/min |
15.9/60 |
15.9/60 |
15.9/60 |
15.9/60 |
|
Cable capacity |
Ft/m |
18.4/5.6 |
41.3/12.6 |
68.9/21 |
92/28 |
