Shandong Hongda Construction Machinery Group Co., Ltd.
China Manufacturer with main products: Hoisting Machinery, Concrete Machinery, Road Construction, Piling Machinery |
Truck-Mounted Concrete Pump / Concrete Truck
| Shipping: | 4 weeks after receiving the advanced payment |
|---|---|
| Payment Terms: | L/C, T/T |
| Place of Origin: | Shandong in China |
|---|
Specifications
Truck-Mounted Concrete Pump / Concrete Truck
Model: HDT5420THB-52/5
Model: HDT5420THB-52/5
Theoretic Output: 125m3/h
Pumping Capacity Index: 586Mpa. M3/h
Theoretic Pumping Pressure: 8.5Mpa
Hopper Volume: 700L
Feeding Height: 1400MM
Distributing Valve Form: S-pipe Valve
Max. Distributing Radius: 47.8M
Max. Distributing Height: 51.8M
Max. Distributing Depth: 39.8M
Stretched Distributing Boom Height: 9400M
Distance between Front Landing Legs: 10295MM
Distance between Rear Landing Legs: 10650MM
Distance of fore-and-after Landing Legs: 10310MM
Diameter of Conveying Pipe: 125MM
Length of Tailor Hose: 3M
Rotary Range of Distributing Boom: 365°
Number of Boom Section: 4
Rotary Angle of Each Boom Section: 90° /180° /180° /180° /270°
Close-control Distance: 33M
Remote Control Distance: 200M
Max. Speed: 80KM/H
Min. Turning Radius: 12500MM
Brake Distance: 10M
Approach Angle: 16°
Departure Angle: 11°
Chassis Model: HOWO ZZ5437S5067C1 HINO Engine/
HOWO ZZ5437S5067C1 SINOTRUCK Engine
Wheel Base between the First and Second Axle: 1800MM
Wheel Base between the Second and Third Axle: 5000MM
Wheel Base between the Third and Fourth Axle: 1350MM
Front Thread: 2022MM
Rear Thread: 1830MM
Max. Engine Output: 259KM(2100R/MIN)/275KM(2200R/MIN)
Max. Engine Torque: 1460N. M(1100R/MIN)/1500(1100-1600R/MIN)
Max. Gradient Ability: 37%
Fuel Consumption Limit: 38L/100KM
Overall Dimension: 13990MM*2500MM*4000MM
Laden Weight: 42000KG
